Power Amplifier with PID Module manufactured by Vickers. This EEA-PAM-513-D-32 Card is For Proportional Valve KCG-3, KCG-6/8, KX(C)G-6/8 and has a Power (Input) Supply of 24V DC.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

EEA-PAM-513-D-32

  • Rated 4.7 (29 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
Power Amplifier with PID Module manufactured by Vickers. This EEA-PAM-513-D-32 Card is For Proportional Valve KCG-3, KCG-6/8, KX(C)G-6/8 and has a Power (Input) Supply of 24V DC.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a EEA-PAM-513-D-32 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The EEA-PAM-513-D-32 is a D series power amplifier from Eaton. The company is a manufacturer of power amplifiers for the hydraulics industry. The unit has all the features of the manufacturer’s A series of amplifiers barring the gain factor. It supports a closed-loop operation with user-configurable PID feed-forward. The device operates as a general-purpose integrated module. The module can be configured using various potentiometers and nine DIL switches. The amplifier comes with a warranty period of one year. The manufacturer markets its power amplifier under the brand name Vickers.

The front panel of the power amplifier has two green LEDs that get illuminated when there is a 24V input power supply and a 15V output control supply. The card has a Eurocard style design that makes the installation process very easy. When the PID controller is enabled, the load current is less than or equal to 10mA. The amplifier has an ambient storage temperature range between -25°C and +85°C.  It features a built-in test function. The mode switch helps in the test loop setting, auto function setting, and test valve setting.

The amplifier has a +/-10V reference voltage. A yellow LED gets illuminated on the front panel when the LED is PID-controller enabled. The unit is CE Certified. The unit is intended for use with the manufacturer’s KCG-3, KCG-6/8 and KX(C)G-6/8 proportional control valves. The device has 47 kilo Ohms analog voltage input impedance. Each socket on the front panel has a 2.0mm diameter. The power amplifier can be used as a replacement for two standard electronic cards. It comes with an inbuilt test feature to check the operational status of the device and a ramp function generator. We can send the amplifier to your preferred address of delivery through our team of delivery agents.

  • EEA PAM 513 D 32
  • EEA-PAM-5l3-D-32
  • EEAPAM513D32

EEA-PAM-513-D-32 Technical Specifications

Product type: Power amplifier with PID module
Ambient temperature: 0 to 50 °C
Series: EEA-PAM-5**-D-32
For Proportional Valve: KCG-3, KCG-6/8, KX(C)G-6/8
Power Supply: 24 VDC
Power consumption: 50 W
Control (Output) Supplies: +15V for LVDTs only
Reference voltages: +/- 10V
Mass: 0.4 kg
Storage temperature: -25 to 85 °C

Frequently Asked Questions about EEA-PAM-513-D-32


Q: What is a major benefit of the amplifier?

A: The integrated PID modules enables replacement of two conventional cards.

Q: What are typical amplifier applications?

A: Amplifer applications include closed-loop pressure control and servo-performance control.

Q: How can you configure the integrated module?

A: DIL switches on the amplifier allow configuration of the integrated module.

Q: Does the amplifier feature a built-in test function?

A: The amplifier supports a built-in test function.

Q: What are specifications for the monitor points?

A: The monitor point impedance is 10 kΩ and the voltage range is ±10 V.
