The SM2863-5155 is an AC stepping motor with a step angle of 1.8 and a nominal holding torque of 9.2 Nm. Manufactured by Sanyo Denki, this motor is part of the F SANMOTION Stepping Motors series and supports a power supply voltage of 325 VAC. It features low acoustic noise and dimensions of 85.5x85.5x127 mm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The AC stepping motor SM2863-5155 by Sanyo Denki is a reliable option for various motion control applications. It is manufactured by Sanyo Denki. The motor guarantees low noise levels and high dependability. It gives precise control with a step angle of 1.8. This AC stepper motor is built for high industrial motion demands.
The SM2863-5155 AC stepping motor belongs to the F SANMOTION Stepping Motors Series. It can hold 9.2 Nm of nominal torque. It offers theoretical acceleration of up to 20500 rad/s². This stepping motor comes in NEMA 34 size and the flange is 85.5 mm wide. The RTA X-PLUS B and X-MIND lines of drives can be used with it. The back EMF number of 241 V/Krpm makes the speed control stable. This Sanyo Denki motor operates at a 325 VAC power supply voltage whereas 250 VAC (350 VDC) as the insulation voltage. The motor can take 4 A of current and 1 Ω of resistance. Along with its 7.9 mH inductance to makes sure that energy is moved quickly. The motor body is 127 mm tall, 85.5 mm wide, and 85.5 mm long. It weights 4 kg. The rotor's inertia is 4500 × 10⁺ kg·m² which lets it move quickly and spin easily. It is rated IP43-F, which means it can handle water and dust. The motor is designed to operate efficiently at high power and high temperatures.
The Sanyo Denki prioritizes quality and functionality in their products. The motor performs effectively in devices that need maximum power without vibrations. Even though small, the Sanyo Denki SM2863-5155 has several benefits. As it is durable this stepping motor can work swiftly and steady. This AC stepping motor is ideal for precise machines and systems working successfully in many workplaces.
Frequently Asked Questions about SM2863-5155:
Q: How does the 1.8 step angle of SM2863-5155 benefit motion control precision?
A: The 1.8 step angle allows for 200 steps per full revolution, enabling fine positioning and smoother motion. This is critical in applications requiring exact angular movement and minimal deviation.
Q: Why is compatibility with RTA X-PLUS B and X-MIND drives significant for SM2863-5155?
A: These drives provide optimized current control and microstepping capabilities, enhancing motor performance. They ensure safe operation and simplified integration into advanced systems.
Q: Why is the double shaft configuration of SM2863-5155 beneficial in some applications?
A: A double shaft enables additional sensors or mechanical couplings to be mounted, expanding feedback or drive options. It’s particularly useful in systems requiring encoder-based feedback.
Q: How does the 1 Ω resistance affect the heating characteristics of SM2863-5155?
A: With 1 Ω resistance, the motor balances power consumption and heat dissipation, minimizing internal losses. This helps maintain consistent performance during extended operations.
Q: What advantages does the 4 A current rating offer for SM2863-5155 under load?
A: The 4 A current supports high torque output and thermal stability during heavy-duty operations. It ensures the motor can sustain prolonged activity without overheating.
