The M22NRXC-LSN-NS-03 by Pacific Scientific is part of the PowerMax II M Motor Series. The M22NRXC-LSN-NS-03 is a NEMA mounting motor featuring a holding torque of 1.68 Nm and a rated current of 3.1 Amps DC. It also holds a phase resistance of 3.12 ohms +/- 10% and phase inductance of 3.1 mH Typical.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Pacific Scientific manufactures top-quality motion control equipment. The company's products have been used in industries for many years.

The M22NRXC-LSN-NS-03 is a stepper motor from the POWERMAX II series. The powerful stepper motor comes with the Sigmax Technology that ensures the maximum available torque for any motor. The motor has a rated current of // A per winding and has a weight of 1.13 kg. The M22NRXC-LSN-NS-03 comes with oversized bearings (in contrast to the normal 22 mm bearings). This enhances the motor’s fatigue life. As a result, the motor is able to withstand more cyclic loading. The motor produces a // Nm torque per winding. For increasing the motor’s performance, a concentric air gap is maintained. This is done through a precision rotor and a honed stator. The M22NRXC-LSN-NS-03’s stator is encapsulated using polymer. This enables a greater heat dissipation that ensures an optimum stator temperature.

The M22NRXC-LSN-NS-03 comes with exposed lamination aids that further assist the heat dissipation. As a result, the motor is protected against thermal overload and overheating. In standard configuration, the motor comes 8-pole pin connector. This model has an octagonal housing that has been designed to maintain an optimum motor temperature. A 6.3 mm diameter has been chosen for this model. An increased shaft diameter enables the shaft to better withstand axial and radial loads. The stepper comes with CE approval. The model’s outer enclosure is protected against damage by objects greater than 12.3 mm in size. Protection against water sprays in also ensured because of an IP 23 standard ingress protection. The motor is capable of high short-time dynamic movements because of a low inertia rotor.

  • M22 NRXC LSN NS 03
  • M22-NRXC-LSN-NS-03
  • M22NRXC LSN NS 03
  • M22NRXC-LSN-NS-O3
  • M22NRXCLSNNS03
  • M22NRXCLSN-NS-03

M22NRXC-LSN-NS-03 Technical Specifications

:
Detent Torque : 0.12 Nm
Holding Torque: 1.68 Nm
Phase Inductance: 3.1 mH Typical
Phase Resistance : 3.12 ohms +/- 10%
Rated Current/ Phase: 3.1 Amps DC
Thermal Resistance: 4.5 Mounted degree Celsius/ Watt
