Product Description:

The 33VM62-028-5 low-inertia servomotor is manufactured by Pacific Scientific and is part of the Low Inertia PMDC Servomotors series. It is a compact permanent-magnet DC unit intended to drive light mechanical loads that must start, stop, and reverse rapidly in automated assembly cells, conveyors, or indexing fixtures. By combining armature current control with a feedback device, the motor supplies repeatable torque and velocity so motion controllers can hold target positions without mechanical backlash compensation. This arrangement supports precise acceleration and deceleration on axes that cycle frequently and cannot tolerate long settling times.

The motor’s electromagnetic core uses a Permanent Magnet DC topology, and its field flux is established by Alnico V-7 magnets that maintain stable remanence over a wide temperature range. Because the motor uses no forced-air cooling, heat is removed through natural convection, allowing installation where fans would introduce contamination. Rotor speed data come from an optical incremental encoder whose light-based sensing tracks shaft rotation without contact wear. For velocity smoothing at low speeds, a standard analog tachometer is mounted on the rear housing, and its generated voltage is proportional to rpm. The encoder provides position-related pulses, while the tachometer supplies a continuous voltage signal for analog speed regulation.

The encoder supplies dual quadrature channels so the controller can distinguish direction while maintaining four-times interpolation accuracy. A once-per-revolution home marker, designated as a Zero Index, simplifies absolute position referencing after power-up. Each track outputs a square wave signal that is compatible with typical 5 V differential receivers used in digital drive interfaces. These feedback signals let the control system monitor shaft movement continuously during reversals and short moves. The rotor’s reduced moment of inertia allows fast step response without demanding large current spikes from the drive, which suits short-stroke applications.
