2VM62-000-11 Pacific Scientific
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
11 Seconds
The Pacific Scientific 2VM62-000-11 is a servomotor from the Low Inertia PMDC Servomotors series, designed with air inlet and outlet cooling and no baffles. It provides a rated output power of 650 W at a rated speed of 2400 RPM, with a rated voltage of 72 V and rated current of 18.2 A. This model features a medium torque-constant winding and is paired with a coupled vendor analog tachometer.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The 2VM62-000-11 is a permanent-magnet DC servomotor produced by Pacific Scientific within the Low Inertia PMDC Servomotors series. As a low-inertia unit, it accelerates and decelerates rapidly, making it suited for pick-and-place heads, indexing tables, and other motion axes that must follow frequent speed commands inside automated machinery. When paired with an external drive, the motor converts electrical power into controlled shaft torque and position feedback for closed-loop industrial automation tasks.
The motor’s electrical ratings define its continuous operating window. A supply of 72 V produces a continuous armature current of 18.2 A, yielding the name-plate shaft speed of 2400 RPM. Under these conditions the armature delivers 650 W of mechanical output, appropriate for mid-frame actuators that demand quick but moderate power bursts. Heat that cannot be transferred out of the laminations is quantified by a thermal resistance of 0.34 °C/W; this figure links the electrical loss in the windings and bearings to the predictable rise in case temperature and guides enclosure airflow requirements.
Transient duty and auxiliary features complete the performance profile. During short accelerations the armature can accept a pulse current of 58 A without demagnetizing the permanent magnets, allowing rapid torque generation beyond the continuous limit. Internal losses at stall and during dynamic braking are restricted to a power dissipation of 350 W, so external cooling must move that heat away. The housing vents rely on an air inlet and outlet with no baffles path, and an externally mounted, coupled vendor tachometer supplies analog velocity feedback because no optical encoder is attached. Finally, the armature winding is constructed with a medium torque-constant design that balances torque sensitivity against back-EMF, enabling smooth integration with standard DC drives.
Frequently Asked Questions about 2VM62-000-11:
Q: What is the rated speed of the 2VM62-000-11 servomotor?
A: The 2VM62-000-11 servomotor operates at a rated speed of 2400 RPM for continuous motion applications.
Q: What kind of analog tachometer is used in the 2VM62-000-11 servomotor?
A: This model uses a coupled vendor tachometer for analog feedback, which assists in speed regulation.
Q: What is the rated current specification for the 2VM62-000-11 servomotor?
A: The rated current for the 2VM62-000-11 is 18.2 A, supporting moderate to high load requirements.
Q: How is the 2VM62-000-11 servomotor cooled?
A: The 2VM62-000-11 uses air inlet and outlet cooling without internal baffles for heat dissipation.
Q: What is the rated output power of the 2VM62-000-11 servomotor?
A: The rated output power of the 2VM62-000-11 servomotor is 650 W, enabling it to drive medium-duty loads.
