K32HSFL-LNK-NS-02

  • Rated 4.4 (15 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: In-Stock, Ships 1-2 Days
  • Call for Expedited Shipping and Product Condition Options
K Series POWERPAC Hybrid Step Motor manufactured by Pacific Scientific. This POWERPAC Hybrid Step Motor features a Mounting Configuration of Heavy duty NEMA along with a Size of NEMA 34 frame size; 3.38 width/height, square grame.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

K32HSFL-LNK-NS-02

  • Rated 4.4 (15 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: In-Stock, Ships 1-2 Days
  • Call for Expedited Shipping and Product Condition Options
K Series POWERPAC Hybrid Step Motor manufactured by Pacific Scientific. This POWERPAC Hybrid Step Motor features a Mounting Configuration of Heavy duty NEMA along with a Size of NEMA 34 frame size; 3.38 width/height, square grame.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a K32HSFL-LNK-NS-02 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The K32HSFL-LNK-NS-02 is manufactured by Pacific Scientific as a hybrid stepper with powerful torque to frame size ratio. It belongs to the Sigmax Type Powerpac K series notable for high torque performance. It produces excellent torque and high level of acceleration due to its stator design and optimized magnetics. There is also the functionality of low detent torque which allows a seamless micro stepping.

The K32HSFL-LNK-NS-02 is equipped with an extra set of magnets in the stator slots to increase the rotating force at the identic motor size. This hybrid stepper motor comes in NEMA 34 and 42 dimensions with a square housing. The NEMA motors are rugged with size 90 and 110 mm which combines well with a rotor of large diameter and rotor-stator for faster rotation and comfortable micro stepping.  It also comprises of an 8-pole flying lead connection.

Pacific Scientific also integrates flux-focusing SIGMAX technology into the K32HSFL-LNK-NS-02 motor stepper for more significant acceleration which produces 25 percent more turning force. It comes with two stacks of the rotor, large winding type, and 10.7 Nm holding torque per winding. It’s rated current and resistance is 8.1 A and 0.52 Ohm respectively per winding. Its rotors are laminated with a single shaft configuration and straight key shaft. It has a little weight of 3.8kg but punches well above its weight when it comes to efficiency.

Some of the K32HSFL-LNK-NS-02 notable features include:

  • The motor is Size NEMA 34 and 42
  • Straight Keyway Shaft
  • Full Step Angle 1.8°
  • The Front Bell comprise of Long-life Steal Bearing Bore
  • 2-Phase Hybrid Stepper
  • Magnetic Design Optimized for Enhanced Performance
  • Class IP 44 Protection
  • The rotor inertia is 0.27 kgm2×10-3
  • K32-HSFL-LNK-NS-02
  • K32HSFL LNK NS 02
  • K32HSFL-LNK-NS-O2
  • K32HSFLLNKNS02

K32HSFL-LNK-NS-02 Technical Specifications

Basic Series: Sigmax
Encoder Option/Special Sequence: No feedback/Special
Size: NEMA 34 frame size; 3.38 width/height, square grame
Number of Rotor Stacks: 2 Stacks
Mounting Configuration: Heavy duty NEMA
Construction/Hookup: Special
Winding Leads: 8 Lead
Winding Type: Standard
Rotor Type: Laminated
Shaft Configuration/Shaft Modifications: Single/Straight Key

Frequently Asked Questions about K32HSFL-LNK-NS-02


Q: What shape is the motor housing?

A: The motor housing has a square shape.

Q: What is the benefit of using rare earth magnets for motor construction?

A: Rare earth magnets provide high demagnetization resistance.

Q: What is the benefit of large motor bearings?

A: Oversized bearings provide long operating life and withstand high axial and radial forces.

Q: What is the full step angle?

A: The full step angle is 1.8°.

Q: What is the motor protection class?

A: The protection class is IP44.

Internal Product Review

  • ‘‘K32HSFL-LNK-NS-02 is a 2-step hybrid stepper motor that is ideal for many applications.’’
