Product Description:

The OSP-P200LA-R is an operator-panel monitor produced by Okuma for the OSP CNC Monitors series. It serves as the primary human-machine interface on compatible machine tools, presenting programming data, position feedback, and system alarms directly at the workstation. By linking the numerical control to the operator, the monitor supports precise setup, real-time verification, and on-screen diagnostics during machining operations. This arrangement keeps key status information visible at the machine instead of requiring a separate display terminal.

The unit uses a 15 in active-matrix screen that is large enough to show multiple information windows at the same time. The control resolves numeric entries to 8 decimal digits, allowing small offsets to be entered with very fine granularity. Linear movements can be commanded in steps as small as 0.001 mm, while rotary commands reach an angular resolution of 0.001°. Each block of NC code can contain up to 158 chars, which helps keep longer multipart commands on one line. That capacity reduces the need to split complex instructions into additional short lines during editing. Position detection is full-range absolute, so the system does not require a homing routine after power-up.

Program storage is organized through a three-level directory structure, and sequence and program identifiers are limited to four characters for compact naming. Simultaneous motion control supports 3 composite axes for coordinated milling and 2 turning axes when the monitor is paired with lathe applications. Tool data handling includes 32 offset records and the same number of selection tables, so wear values and alternate tool calls remain available during longer runs. File handling also uses three-character extensions, which keeps naming conventions simple across stored routines. This layout keeps program folders and tool-related data organized in a predictable way during daily use.
