Product Description:

The SV3410-00000 is a flux-vector AC drive produced by Kollmorgen and supplied within the SV3000 Flux Vector Drives series. As a closed-loop motor controller, it regulates torque and speed for induction machines used in conveyors, mixers, and material-handling lines. By adjusting output frequency and voltage in real time, the drive supports precise acceleration profiles and consistent low-speed torque. This control method helps the connected motor maintain stable performance when load demand changes during normal operation. It is suited for applications that need controlled starts, steady running speed, and repeatable deceleration without mechanical ratio changes.

Electrical characteristics show how the unit interfaces with plant power. It accepts 460 VAC on a three-phase supply and draws 13.1 A at full load, so branch protection uses a KTK-20 fuse rated 20 A. A displacement factor of 0.86 means incoming power is used efficiently, and the inverter stage is sized for 11 kVA apparent output. Nominal output current is 14.0 A, and an internal fan starts with the first enable signal for forced airflow. The chassis or panel-mount package places all terminals on the front edge, which keeps power and control connections accessible during installation. Front-facing terminals also reduce cable crossing inside the panel. At startup, vector control produces 150% rated torque at 3 Hz, letting loaded motors overcome static friction without external soft starters.

For brief overloads, the drive can deliver 150% for 60 seconds, pushing phase current to 21.0 A before automatic rollback. Continuous mechanical power is 10 HP, and its internal brake torque is 30%, absorbing regenerated energy to shorten stops when no external resistor is present. At a 6 kHz carrier, heat loss reaches 240 W, and the internal fan removes this heat from the sink. Overcurrent supervision compares normal operation with the permitted peak envelope so the power stage can trip safely during fault conditions. This response helps the drive manage short process disturbances while protecting the inverter section from extended stress.
