Product Description

Kollmorgen provides worldwide services in the manufacturing and development of cost-effective servo amplifiers, power supply modules, and drive converters for various industrial sectors.

The SP10600-504A2 model reflects the latest motion control technology of Kollmorgen and is widely used in various industrial automation applications. The SP servo amplifier is equipped with a standard interface for developing communication between the module and the motor. The unit is used together with the respective PA power supply unit specified by the supplier. The PA power supply module takes electrical power from the 3-phase power source and converts it into the stabilized dc-link voltage which is then supplied to operate the servo amplifier. The SP servo amplifier should only be used according to the operating conditions specified in the SP user manual. The input voltage requirement for this unit is 125 – 360 Vdc and the unit consumes the rated power of 1.26 to 2.79 kVA. The module belongs to the SERVOSTAR SP series drive and is recommended to be installed in a switchgear cabinet of minimum IP54 protection. The servo amplifier should be mounted in the vertical direction with sufficient ventilation left to overcome the heat effect generated due to 84 W of internal power loss.

The model SP10600-504A2 is designed to be installed at the maximum altitude of 3300 feet, without derating under the environmental temperature range of 0 to +45 degree Celsius. Make sure that the installation area is free from dust and reactive gases. The rated output current requirement of the SP servo amplifier is 6 A, and it delivers the continuous power of 1.1/2.2 kW at 115/230 V operating voltage. The analog input scaling of this unit is 1.7 A/V and the current feedback scaling is 2.12 A/V. You can order this SP servo amplifier (SP10600-504A2) from Wake Industrial and get it shipped to your provided business address.
