S71201-SENA-NA-0X9

  • Rated 4.4 (34 total ratings)
  • Call for Expedited Shipping and Product Condition Options
The S71201-SENA-NA-0X9 is manufactured by Kollmorgen as part of their S700 Servo Drive Series. These drives feature a Rated line power for S1 operation of 9 kVA and a Peak output current of 24 A RMS. Alongside of a Voltage rating of 208-480 V and a Maximum DC bus link voltage of 900 V.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

S71201-SENA-NA-0X9

  • Rated 4.4 (34 total ratings)
  • Call for Expedited Shipping and Product Condition Options
The S71201-SENA-NA-0X9 is manufactured by Kollmorgen as part of their S700 Servo Drive Series. These drives feature a Rated line power for S1 operation of 9 kVA and a Peak output current of 24 A RMS. Alongside of a Voltage rating of 208-480 V and a Maximum DC bus link voltage of 900 V.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a S71201-SENA-NA-0X9 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Kollmorgen is a leading corporation that supplies motion control systems for automation. Kollmorgen provides a wide collection of devices like AGV components, electric motors, servo drives and motion controllers, having obtained a prominent position in the automation market. The S71201-SENA-NA-0X9 is a model in the Kollmorgen S700 line of digital servo-amplifiers. The amplifier works on a triphase 208 - 480 V AC voltage supply at a frequency of 50/60 hz.

The system could be controlled by a PLC using its SERCOS communication card. The S71201-SENA-NA-0X9 drive is able to provide a continous current of 12 ampere and is able to supply the connected motor a peak current of 24 A for a time below 5 seconds. The environment temperature near the device shall be in the following range: 0… 45 degrees Celsius while the equipment is working and shall be maintained between -25 and 55 degrees Celsius when the module is stored.

The full parametrization of the servodrive should be performed via the DRIVEGUI setup program connecting an ordinary Personal Computer to the amplifier with its integrated RS-232 port (X8).

The S71201-SENA-NA-0X9 offers a primary mono channel safety STO feature that permits the subsystems (servo drives) to gain PLd, according to EN 13849-1 and SIL CL 2 (EN 62061). The S71201-SENA-NA-0X9 is provided with a group of built-in Input/Outputs, such as two analog inputs, four digital inputs and two digital inputs/outputs (selectable direction), that may be configured in order to accomodate the user's needs. The max site height for the system to be mounted to allow the servodrive to run at full power should be 1000 meters above mean sea level, supporting 2500 meters above the sea level practicing energy derating (1.5 % every 100 meters).

S71201-SENA-NA-0X9 Documents

  • S-71201-S-ENA-NA-0X9
  • S-71201S-ENANA0X9

S71201-SENA-NA-0X9 Technical Specifications

Maximum DC bus link voltage: 900 V
Peak output current: 24 A RMS
Rated line power for S1 operation: 9 kVA
Rated output current at 3x208 V: 12 A RMS
Thermal dissipation at rated current : 100 W
Thermal dissipation, Output stage disabled: Max. 20 W
Voltage rating: 208-480 V
