The PMX Stepper Motors series is a family of hybrid, 2-phase stepper motors designed to provide precise incremental motion in a compact package.
The series covers six frame sizes from NEMA 08 through NEMA 34, with multiple stack lengths and winding options that allow the motors to be matched to different torque, size, and control requirements. Across the lineup, the motors are brushless and maintenance-free, and they are built with options such as front shaft flats, rear shafts, integral connectors, and, on certain models, rear encoder mounting provisions. Depending on frame size, the series supports bipolar windings throughout and also offers unipolar winding choices on selected PMX17 and PMX23 models, while additional customization is available for shafts, cables, connectors, encoders, and gearbox assemblies. The PMX Stepper Motors series is also built for industrial integration with Class B insulation, a maximum case temperature of 130°C, and compliance with CE, RoHS, and REACH requirements.
