Product Description

The MSM100-14-604-E2-0KA is a High-energy servo motor in the MSM series from Sheffield Automation. The basic features of this motor include dynamic response, a compact design and performance accuracy. It is intended for use with drive machinery in a normal industrial environment under manufacturer-specified conditions. By design, the MSM100-14-604-E2-0KA leverages an Incremental Encoder Feedback type with no brake, and its frame size is rated at 100. It has a shaft with a keyway and a supply voltage of 460 Volts.

The MSM100-14-604-E2-0KA has a continuous torque rating of 1.53 Nm (14 in-lb), and a peak torque of 8 Nm (71 in-lb). It has a phase-to-phase winding inductance of 22.0 mH, and its winding resistance is 9.0 at 25^o C. The maximum current rating of this MSM servo drive is 17.7 Amperes, its stall current is 3.4 Amperes, and it has a maximum rotor speed of 6,000 rpm. As per net weight, the MSM100-14-604-E2-0KA weighs 5.9 kg (13.0 lb). In addition, it features 6 poles and the moment of inertia of its rotor is rated at 0.00021 kgm². The shaft material typical of this unit is the ST-60 variant.

The operating ambient temperature of the MSM100-14-604-E2-0KA is within the range of 0 to 40 degrees Celsius (32 to 104 degrees F). Also, it has an admissible storage temperature range of -30 to 70 degrees C, and a non-condensing relative humidity of 5 to 95 %. The standard motor radial load force of MSM100 servo motors is 76 lb. The outer surface temperature of the MSM100-14-604-E2-0KA can rise as high as 125 degrees Celsius – precaution must be taken to avoid injuries resulting from accidental contact with high-temperature surfaces.
