MMC-SD-2.0-230-DN
Wake Industrial LLC is not an authorized distributor of this product.
MPN: M.1302.8911
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships in 3 Days
The MMC-SD-2.0-230-DN drive offers a continuous torque stall of 74.6 lb-in, peak torque stall of 190 lb-in, and operates up to 1920 RPM at 230 Vac. As part of the MMC Standalone Smart Drive Series by Kollmorgen, it features a motor type of AKM52G-BNC, brake inertia of 0.00015 lb-in-s2, and motor weight of 12.8 pounds.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Kollmorgen offers the MMC-SD-2.0-230-DN (M.1302.8911) smart drive for applications requiring precise motion control in robotics. The drive is an efficient and dependable solution for demanding control requirements due to its steady performance.
The MMC-SD-2.0-230-DN smart drive requires a nominal input current of 18 Amps RMS to function at both 120 and 230 volts AC. At 120 VAC, it needs a 2 kVA transformer, and at 230 VAC, it needs a 4 kVA transformer. To further improve system performance, a single-phase AC line filter with a 10A current rating and a 250V voltage rating can be used to reduce electrical noise and guarantee steady input conditions. The input power design of the system is enhanced by the AC line filter's single-phase voltage rating. The M.1302.8911 drive's power rating configuration may satisfy industrial automation requirements. The 600V rating of the shunt resistor contributes to effective energy dissipation during rapid braking. The drive guarantees reliable and constant operation in motion control settings thanks to its exact technological features and power handling capabilities. Our extensive one-year replacement warranty is our way of assuring quality.
The MMC-SD-2.0-230-DN smart drive has a strong control design to help with operational efficiency. A consistent power supply regardless of the load is guaranteed by the device's protective specifications and transformer size. For both input voltages, a maximum fuse size of 30A is recommended for safety. A dynamic shunt resistor module with a resistance of 100Ω, a power rating of 300W, and a voltage rating of 600V is integrated into the M.1302.8911 smart drive.
Frequently Asked Questions about MMC-SD-2.0-230-DN:
Q: Why does the MMC-SD-2.0-230-DN require 30A fuses?
A: The 30A fuse size provides adequate protection against overcurrent to prevent damage to the drive. It ensures operational safety during voltage surges.
Q: How does MMC-SD-2.0-230-DN handle braking energy dissipation?
A: The drive features a 100Ω, 300W dynamic shunt resistor that dissipates excess braking energy. This prevents overheating during dynamic braking.
Q: Why is a 4 kVA transformer used for 230VAC input?
A: The 4 kVA transformer provides sufficient power to handle high-performance operations at 230VAC. It ensures reliable voltage regulation during peak loads.
Q: Does MMC-SD-2.0-230-DN support noise suppression in power input?
A: Yes, the 10A AC line filter at 250V suppresses electrical noise. It maintains stable input power by filtering unwanted fluctuations.
Q: Why is the shunt resistor of MMC-SD-2.0-230-DN rated at 600V?
A: The 600V rating ensures that the resistor can withstand high voltage spikes during regenerative braking. This enhances overall durability and safety.
