LSM63-12-602-E1-2KA

  • Rated 4.5 (25 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options
The LSM63-12-602-E1-2KA was manufactured by Kollmorgen as part of their LSM Brushless Servo Motor Series. It features a Continuous Torque of 1.4 Nm and a Peak Torque of 1.32 Nm. It also provides a Stall Current of 1 amp and a Maximum Current of 3.8 amps.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

LSM63-12-602-E1-2KA

  • Rated 4.5 (25 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options
The LSM63-12-602-E1-2KA was manufactured by Kollmorgen as part of their LSM Brushless Servo Motor Series. It features a Continuous Torque of 1.4 Nm and a Peak Torque of 1.32 Nm. It also provides a Stall Current of 1 amp and a Maximum Current of 3.8 amps.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a LSM63-12-602-E1-2KA to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Kollmorgen is an international supplier of industrial automation products. The company offers a broad range of brushless servo motors, stepper drives, and frequency converters.

The LSM63-12-602-E1-2KA model is highly recommended by our customers around the globe due to its cost-effective applications and maintenance-free operation. The LSM63 brushless servo motor is equipped with a rotor with a keyway for continuous power delivery at the motor’s output shaft and a shaft sealing ring is also placed to avoid leakage. A standard bearing with 20,000 hours operating life is placed in this unit. The LSM63 brushless servo motor can bear the maximum radial force of 28 kg while operating at the speed of 500 rpm and while operating at the speed of 6000 rpm the maximum allowable radial force by the unit is approximately 23 kg. The servo motor by Kollmorgen operates at the rated voltage of AC 230 V, supplied by the respective servo drive. The model should only be used together with the servo drive module prescribed by the supplier. Only highly trained personnel are allowed to operate the servo motor. During installation, make sure that the mounting surface is clean and the unit is configured according to the required operation. The overall weight of the LSM63 servo motor is 1.8 kg, excluding the weight of accessories and holding brake.

The model LSM63-12-602-E1-2KA provides high dynamics when used according to the mounting and environmental conditions specified by Kollmorgen. The servo motor provides high-speed point-to-point positioning and it is developed under ISO9000 facility. The motor comes with an easy installation option and it consumes 4.1 A of continuous current to generate the continuous torque of 1.4 Nm. An electrically released 24 VDC holding brake is installed in this model along with an E1 incremental encoder for position detection.

  • LSM6312602E12KA
  • LSM-63-12-602-E1-2KA
  • LSM6312-602-E1-2KA

LSM63-12-602-E1-2KA Technical Specifications

Product type: Servo motor
Winding resistance: 2.26 Ohms
Input voltage: 230 VAC
Continuous torque: 1.4 Nm
Peak torque: 5.6 Nm
Speed: 6000 RPM
Stall current: 4.1 Amps
Max current: 15.8 Amps
Weight: 1.8 kilograms
Poles: 8

Frequently Asked Questions about LSM63-12-602-E1-2KA


Q: What are available LSM motor options?

A: Available options include 24 VDC brake, single-turn high-resolution encoder and multi-turn high-resolution encoder.

Q: Under which conditions should the motor not be turned-on?

A: The motor must not be turned on if it is unmounted or if there are any disconnected couplings or cables.

Q: What is the benefit of a drip loop?

A: A drip loop in cables connected to the motor keeps liquids flowing away from the motor.

Q: What are best practices for protecting the motor from EMI?

A: Best practices for countering EMI include filtering AC power, separating and shielding signal carrying lines, and providing proper earthing.

Q: How hot can the motor surface get?

A: The motor surface can reach temperatures of up to 125 degrees Celsius. Precautions must be taken to prevent serious burns and injury.

Internal Product Review

  • ‘‘LSM63-12-602-E1-2KA is a high-performance brushless servo motor from Kollmorgen.’’
