The B-104-B-32 is manufactured by Kollmorgen as a part of their Goldline B/BH Motor Series. These motors feature a max BUS of 320 and a max stall tc of 20.9 lb-in. As a low inertia motor, it features a max speed of 5600 RPM and a max rated power of .90 kW.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The model B-104-B-32 is a brushless servomotor belonging to the popular Goldline series introduced by Kollmorgen. The company is known for producing hi-tech PLC solutions, such as servo motors, for a wide range of applications. The Goldline series by Kollmorgen offers a wide range of servomotors. These motor feature continuous torque ranging between 0.84 Nm to 111.2 Nm. Moreover, they are available in a square frame with sizes between 70mm and 190mm. The Goldline series is categorized into 3 families on the basis of rotor-inertia. The B series offers the lowest rotor inertia while the M series delivers medium rotor-inertia. The EB series features explosion-proof models, and they deliver the highest torque.
The B-104-B-32 brushless servomotor has a length of 213.7 mm excluding the length of the exposed shaft. The housing of the servomotor offers IP65 protection and features two angular connectors on top. One of the connectors is meant for connecting the frameless feedback resolver, while the other one is meant for 230-V power supply. The B-104-B-32 brushless servo features a shaft with a keyway to ensure a smooth transfer of power, torque, and speed. The motor’s rotor features a rare-earth magnet that produces a high amount of power. The servomotor has a rated power up to 2.0 HP and a rated speed of 7500 RPM. Even under high temperatures, the motor delivers exceptional performance thanks to H-class insulation that can withstand up to 150 degrees Celsius.
The B-104-B-32 servomotor by Kollmorgen offers a continuous torque up to 1.57 Nm (at 40 degrees Celsius) while its maximum torque is 4.45 Nm. The low rotor-inertia enables the servomotor to accelerate and decelerate quite rapidly. The servomotor weighs 3.2 kilograms.
