DSA 046-460-S

  • Rated 4.5 (13 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: M.1301.5647
    In-Stock, Ships 1-2 Days
  • Call for Expedited Shipping and Product Condition Options

The DSA 046-460-S is manufactured by Kollmorgen as part of their retired DSA Drive Series. This part features an input voltage of 100-240 Vrms Single Phase and an input frequency of 47-63 Hz. The DSA 046-460-S also holds an AC input current of 18 A rms and a continuous output of 10 A.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The Kollmorgen DSA 046-460-S is an advanced digital servo drive. It is configured through the DSAPro software which is a Windows based application that allows drive configuration to be done off-line and then saved to disk. A user manual is not shipped with the drive. However, the manual can be requested at the time of order and will be included at no extra charge. Dimensions of the DSA 046-460-S are as follows: height of 360.7 millimeters, width of 151.6 millimeters and depth of 242.4 millimeters. Input voltage rating for the DSA 046-460-S is three-phase 230 to 480 Volts AC. The auxiliary AC input current specifications include 0.55 Amps nominal current at 230 Volts AC, 0.35 Amps nominal current at 360 Volts AC and 0.25 Amps nominal current at 480 Volts AC.

The main AC input current specifications include 14 A nominal input current at 460 Volts AC and 6 Amps maximum inrush current at 460 Volts AC. The rated continuous output current is 23 Amps. The rated intermitted output current is 46 Amps. Internal shunt on the DSA 046-460-S has a continuous power rating of 200 Watts and a peak power rating of 16 kilowatts. The external shunt on the DSA 046-460-S has a continuous power rating of 10 kilowatts and a peak power rating of 16 kilowatts, and a minimum resistance of 40 Ohms.  The continuous power ratings of the DSA 046-460-S are 5 kilowatts at 230 Volts AC input and 10 kilowatts at 460 Volts AC input. The DSA 046-460-S absorbs 88 Joules at 230 Volts AC with a 230 Volt motor and 776 Joules at 230 Volts AC and a 460 Volt motor.

  • dsa 046-460-s
  • dsa-046-460-s

DSA 046-460-S Technical Specifications

AC Input Current Nominal: 18 A rms
AC Input Frequency: 47-63 Hz
AC Input Voltage: 100-240 Vrms Single Phase
Continuous Output Current: 10 A
Output Peak Current : 30 A
