DH062M-12-1310 Kollmorgen
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Kollmorgen DH062M-12-1310 is part of the DDR Direct Drive Motors series and features a single bearing design and a 6.93 inch outer diameter motor frame. It delivers a continuous torque of 7.2 lb-ft with a peak torque of 24.7 lb-ft and operates at 400/480 VAC. The motor has a sine encoder for feedback with 134,217,728 counts per revolution and a repeatability of less than 1 arc-second.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DH062M-12-1310 is a direct-drive rotary motor produced by Kollmorgen within the DDR Direct Drive Motors series. By coupling its stator and rotor directly to the load, the device removes intermediate gearing, which reduces compliance and maintenance. That configuration makes the motor suitable for precision indexing tables, semiconductor metrology stages, and other automation tasks that need rapid, accurate rotary positioning. Its frameless form factor lets machine builders embed the torque source inside their own mechanical housing.
Performance begins with 7.2 lb-ft of continuous torque that the laminated core can sustain without exceeding its thermal limit. For short moves or dynamic starts, available output rises to 24.7 lb-ft, while the rotor reaches a ceiling of 800 rpm before voltage boost is required. The three-phase windings are designed for a plant bus of 400/480 VAC, matching the motor series code. An internal feedback device supplies 134,217,728 counts/rev, giving the controller angular resolution finer than one millionth of a turn, and the reflected inertia of 0.0071 kg-m² balances acceleration with damping on medium-mass loads. These figures are packaged in a 6.93-inch outside-diameter frame that uses a single-bearing design to maintain axial rigidity and minimize runout.
Axis quality is underscored by <1 arc-sec repeatability and overall feedback accuracy of ±26 arc-sec, numbers that simplify compliance with stringent positioning tolerances. A sine encoder specified for the M winding type delivers this fidelity, and the coils use the standard winding scheme referenced as standard with a sine encoder. Integration favors a straight power and feedback connector, a face-mount pilot for concentric seating, and a straight through-bore shaft with face coupling that transmits torque without keys. Because the housing is not sealed, the motor must be placed inside a clean, protected environment. Total mass registers at 11.3 kg, which is light enough for gantry axes while still helping damp vibration.
Frequently Asked Questions about DH062M-12-1310:
Q: What type of feedback and resolution does the DH062M-12-1310 direct drive motor provide?
A: The DH062M-12-1310 is equipped with a sine encoder feedback device and supports a resolution of 134,217,728 counts per revolution.
Q: What is the continuous torque rating of the DH062M-12-1310?
A: This model offers a continuous torque of 7.2 lb-ft, suitable for precise motion control in demanding applications.
Q: What is the maximum operating speed of the DH062M-12-1310?
A: The maximum speed for the DH062M-12-1310 direct drive motor is 800 rpm.
Q: What bearing configuration is featured in the DH062M-12-1310?
A: The DH062M-12-1310 uses a single bearing design for its moving components.
Q: What operating voltage does the DH062M-12-1310 require?
A: This model operates at an input voltage of 400/480 VAC.
