CTM22NLS12NAA00

  • Rated 4.4 (5 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options

The CTM22NLS12NAA00 is manufactured by Kollmorgen as part of the CT stepper motor series. It features an inductance of 14 mH and a current of 1.2 amps. It also includes a thermal resistance of (Mounted °C/Watt) 2.62 and a resistance of 8.26.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The CTM22NLS12NAA00 is a Cool Torque Maximum series step motor from Kollmorgen. The step motor features a high torque magnetic design and offers high performance. The motor also uses patented enhancing technology to provide maximum torque and efficiency when operating at any speed. It has 5.7cm / Size 23 frame size and 2 stack length. The device features 8.26 +/-10% Ohms resistance. We can offer you the step motor with a warranty period of one year.

The step motor features leads connection/construction style, with six leads and a unipolar rating. The #22AWG leads have 12 inches length. The motor comprises two phases, 340VDC insulation voltage rating and 1.2ADC current rating. The device encompasses a high voltage insulation system. The unit completes 200 full steps for each revolution. It has additional rare earth magnet inserts in between two stator teeth to block the flow of surrounding magnetic fields. The device features 100Megaohms insulation resistance and 14mH typical inductance. The unit has 3.32 inches maximum length that makes it quite compact in size.

The motor supports NEMA Through Holes mounting configuration using four mounting holes. It has 1.2A winding current and a round smooth front shaft. The device has no rear option. The unit features Class B insulation at 130°C. The RoHS compliant step motor comes fitted with heavy-duty bearings. It operates between -20°C and +40°C. The step motor has a 1.8° step angle and +/-3% step accuracy. The device is capable of accommodating 20LBS radial shaft load at the center. The unit comes with a long lifespan because of its ability to generate high torque at a low temperature. It is equipped with aluminum end-caps and a shell for fast heat dissipation. The step motor can be dispatched safely to your address through our reliable delivery partners.

  • CTM22NLS12NAAOO
  • CTM-22NLS12-NAA00

CTM22NLS12NAA00 Technical Specifications

Current Amps DC: 1.2
Inductance: 14 mH
Net Weight: 2.5 lbs
Resistance ohms ±10%: 8.26
Thermal Resistance: (Mounted °C/Watt) 2.62
