The Kollmorgen CTP32NLS58KAA00 is a stepper motor in the CT Stepper Motors series with a size 34 frame and a straight keyway shaft. It provides a holding torque of 890 oz-in, supports an axial shaft load of up to 100 lbs in both directions, and features a connection style with six leads. The motor is rated at 5.8 A per phase and 3.7 VDC, with a step angle of 1.8 degrees.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The CTP32NLS58KAA00 is a hybrid stepper motor manufactured by Kollmorgen for the CT Stepper Motors series in the Cool Torque Performance family. Designed for industrial automation, it converts pulse trains into incremental motion for slides, rotary tables, and pick-and-place heads without feedback. Its NEMA 34 footprint allows it to replace legacy units while providing the higher torque density associated with this motor class. This layout is well suited to open-loop positioning tasks where repeatable step movement is required.
The motor uses a NEMA Size 34 frame, measuring 8.5 cm, with NEMA through holes for direct front-face mounting. Its two-stack construction keeps the body depth to 3.80 in, yet the rotor delivers a holding torque of 890 oz-in to maintain position under load. During motion, each 1.8° full step is produced by a 2-phase winding set that draws a rated current of 5.8 A per phase at 0.65 Ω, and the phase inductance of 2.8 mH helps keep current rise times short while staying below the 340 VDC insulation limit. Rotational response is influenced by a rotor inertia of 0.0370 oz-in-s², and axial thrust loads up to 100 lbs can be applied in either direction without exceeding bearing limits.
A detent torque of 30 oz-in helps resist drift when power is removed, and the six-lead design allows series or parallel wiring. This gives the motor flexibility when it is matched to drives with different current and speed requirements. Radial load at the shaft center is limited to 65 lbs, and the straight keyway simplifies coupling to mating components. Within the Cool Torque Performance family, the motor produces 9.5 N-m of bipolar torque in CTM wiring or 7.8 N-m in the CTP connection when supplied with 3.7 VDC. A thermal resistance of 1.55 °C/W helps control temperature rise, the rear configuration has no added hardware, and the overall mass is 6.5 lb.
Frequently Asked Questions about CTP32NLS58KAA00:
Q: What is the holding torque capability of the CTP32NLS58KAA00 stepper motor?
A: The CTP32NLS58KAA00 stepper motor offers a holding torque of 890 oz-in, providing strong positional stability for demanding applications.
Q: What type of shaft does the CTP32NLS58KAA00 have?
A: This model utilizes a straight keyway shaft, allowing reliable torque transfer to the connected load.
Q: How many electrical connections does the CTP32NLS58KAA00 support and what is the connection style?
A: The CTP32NLS58KAA00 supports six electrical connections via leads, ensuring flexible wiring options.
Q: What is the rated current per phase on the CTP32NLS58KAA00?
A: The rated current per phase for this stepper motor is 5.8 A, which supports higher power operation.
Q: What mounting style is provided on the CTP32NLS58KAA00 stepper motor?
A: The CTP32NLS58KAA00 features a NEMA through holes mounting style for straightforward and secure installation.
