The AKM23D-ANBNR-01 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 4.82 Nm. The AKM series also featured a max rated force of 8000 and max rated power of .54 kW.

AKM23D-ANBNR-01

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKM23D-ANBNR-01 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 4.82 Nm. The AKM series also featured a max rated force of 8000 and max rated power of .54 kW.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a AKM23D-ANBNR-01 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Kollmorgen is known for producing dynamic servomotors. The AKM brushless DC motors by Kollmorgen are capable of meeting the most demanding servo applications. The series of synchronous DC motors features seven frame sizes and a wide variety of combinations. The AKM synchronous motors offer industry-leading power to set high standards of in-class performance. They offer smooth performance due to low harmonic distortion and low cogging.

The AKM23D-ANBNR-01 brushless synchronous motor belongs to the AKM2 family featuring a 1.38kg weight, 58mm flange, rare-earth magnet, F-class insulation material, and other additional features. The flange of the servo motor conforms to the standard set by the International Electro-technical Commission. The neodymium-iron boron magnet material offers strength and flexibility to produce high-accuracy results. The AKM23D-ANBNR-01 servomotor is capable of reaching up to 770W power with a top speed of 8000 RPM. To achieve the maximum power, speed and torque, the 400V or 430V variants can be used. The synchronous motor features a smooth shaft with a sealing ring for improved environmental protection. The brushless motor can be connected to the SERVOSTAR certified servo amplifiers via connector available at the top. A built-in resolver features a UL listed lead.

The AKD23D-ANBNR-01 brushless motor offers 1.16 Nm of standstill torque and 2.19 amperes of electric current. The torque of the motor peaks at 3.84 Nm. Even when it’s operating at top speed delivering maximum torque, the motor maintains its ambient temperature below 40 degree Celsius because of the high-insulation winding coated with PUR and PETP material. The F-class insulation offers high temperature tolerance, up to 155 degree Celsius. The AKM23D-ANBNR-01 synchronous motor is cURus and CE compliant, and bears UL recognition.

  • AKM-23D-ANBNR-01
  • AKM23D-ANBNR-O1

AKM23D-ANBNR-01 Technical Specifications

Frame Size: AKM2
Frame Size:
Max BUS (VDC): 640
Max Rated N: 8000
Max Rated Power at Max BUS: .54 kW
Max Stall Tc: 1.4 Nm
Max Tp: 4.82 Nm
Stack Length: 3
