Product Description:

The AKM23D-ACCNR-01 is a servomotor produced by Kollmorgen within the AKM Synchronous Servo Motors series. As a rotary actuator for industrial automation, it supplies controlled torque and speed to machine axes that require accurate motion control. Typical applications include indexing tables, packaging equipment, and other positioning systems where repeatable shaft movement is required. Its compact format allows it to fit into motion systems that need precise output without a large motor footprint.

Its electrical interface is provided through 2 SpeedTec Ready connectors, which support quick-lock cable attachment. Position feedback relies on a resolver, a low-impedance analog sensor that tolerates high temperatures and vibration. The internal resolver has 2 poles, so one mechanical revolution produces two electrical cycles for drive commutation. The frame side dimension is 58 mm, giving the motor a square flange size that matches IEC 58 housings. The output shaft has a keyway, so torque can be transferred to couplings without slip. The motor does not include a holding brake, so vertical or overhauling loads require stopping torque from the drive or an external clamp.

The motor comes with a shaft seal at the output end, which helps block lubricant migration and limit dust ingress. Feedback uses single-turn inductive measurement, so absolute rotor position is available within one revolution without multi-turn gearing. Mounting uses an IEC flange with accuracy N, providing standard pilot tolerances for concentricity. The motor uses winding designation D, which corresponds to the electrical characteristics assigned to this rotor length. The resolver package uses feedback hardware size 10/15/21, and the integral customization keeps the motor aligned with AKM family dimensions and inertia ranges used across shared frame sizes.
