Product Description:

The AKI2G-CDB-MOD-07T-000 interface panel is produced by Kollmorgen within the AKI Interface Panels series. As a human-machine interface, the unit links machine controllers to operators, presenting process data and accepting commands through its integrated touchscreen. It serves in packaging lines, assembly cells, and similar automation where its compact color display and protected front plate mount directly into control cabinets. The display gives local access to status pages, alarms, and machine commands without requiring a separate input device.

The panel presents information on a 7 in TFT screen that renders at 800 x 480 pixels, giving sufficient workspace for trend charts and alarm lists. Its LED backlight outputs 350 cd/m² and is rated for 20,000 hours, so visibility remains stable across multi-shift schedules. The resistive touch overlay tolerates gloved operation common on factory floors. An i.MX6 Solo Single Cortex-A9 1.0 GHz processor works with 512 MB of DDR3 RAM to manage graphics, protocol conversion, and data logging without lag. Historical files and project data reside in a 2 GB SSD (eMMC), which protects stored information better against vibration than removable media. This hardware supports smooth screen changes and stable storage during normal machine operation. A 10/100 Base-T RJ45 port enables Ethernet/IP or Modbus-TCP communication, and a single USB 2.0 host with 500 mA output accommodates backup transfers or barcode scanners.

The enclosure measures 204 × 143 × 50 mm, and the required cutout is 189 × 128 mm, so the panel seats flush with standard cabinet doors. During operation, the electronics draw 14.4 W, a useful figure when sizing 24 VDC supplies for multiple displays. Once installed, the front achieves an IP65 seal against dust and washdown water, while the rear maintains an IP20 classification suitable for sheltered interiors. The aluminum chassis weighs only 0.8 kg, allowing use on lightweight hinged panels without additional support, and passive cooling keeps internal temperatures within limits. Its shallow body also helps the unit fit into cabinet doors and pendant housings where rear clearance is limited.
