The AKD-P00307-NBEI-0000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 2000 Watts and a rated supply voltage of 240/480 V. As well as, Rated output current of 3 A and a peak output current of 9 A. AKD drives offer the greatest output in a compact body.

AKD-P00307-NBEI-0000

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKD-P00307-NBEI-0000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 2000 Watts and a rated supply voltage of 240/480 V. As well as, Rated output current of 3 A and a peak output current of 9 A. AKD drives offer the greatest output in a compact body.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a AKD-P00307-NBEI-0000 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The AKD-P00307-NBEI-0000 is servo drive made by Kollmorgen. This product supports dynamic and static IP addresses. The WorkBench software can be used to change the configured IP address in the TCP/IP window through three modes for Fieldbus and network flexibility. The device supports connection using WorkBench only if it is in Op, Safe-Op or Pre-Op state. After setting the rotary switches to a specific value, the B1 button present at the top must be pressed for five seconds. When both the rotary switches have a value of 1, the current state of the servo drive gets stored on the SD card. The product supports a one-year warranty period.

The full IP addressing of the servo drive can be done using the IP.MODE, IP.SUBNET, IP.ADDRESS and IP.GATEWAY keywords. The device comes with a unique MAC address that is printed on the side and cannot be changed by the user. The rotary switches help in changing the CAN-Bus Baud rate as well as saving and loading data to an SD card. The AKD-P00307-NBEI-0000 servo drive has a rated supply voltage of 240/480VAC and a peak output current of 9A +/-3%. It weighs 2.7kg with standard width and 2.9kg with extended width.  There may be multiple faults when a fault condition occurs. The LED displays the fault code of the highest priority fault.

The Drive Overview window displays details of the drive that is connected and in use. The Drive Type field in this window helps in selecting the operational Fieldbus for the servo drive. The Blink button can be pressed to show all the displays for a duration of 20 seconds. Holding down the More button displays additional details such as firmware version, serial number and cumulative on time. The AKD-P00307-NBEI-0000 can be safely dispatched to your address by our reliable delivery partners.

  • AKDP00307-NBEI-0000
  • AKD-POO3O7-NBEI-OOOO

AKD-P00307-NBEI-0000 Technical Specifications

Control Logic, Supply Voltage: 24 V
Control Logic, Supply Voltage:
Current Loop Bandwidth Max.: 2.5-4 kHz
Drive Continous Output Power: 2000 Watts
Peak Output Current: 9 A
Rated Output Current: 3 A
Rated Supply Voltage: 240/480 V
Velocity Loop Bandwidth Max.: 0-800 Hz
