The AKD-B01207-NBAN-0000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 8000 Watts and a rated supply voltage of 240/480 V. As well as, Rated output current of 12 A and a peak output current of 30 A. AKD drives offer the greatest output in a compact body.

AKD-B01207-NBAN-0000

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKD-B01207-NBAN-0000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 8000 Watts and a rated supply voltage of 240/480 V. As well as, Rated output current of 12 A and a peak output current of 30 A. AKD drives offer the greatest output in a compact body.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a AKD-B01207-NBAN-0000 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The AKD-B01207-NBAN-0000 is a servo drive manufactured by Kollmorgen to control servo motors. The combination of a Kollmorgen AKD servo drive and AKM motor means that your choice in control products is easy. It falls under the AKD series and features position indexer drive version, a current rating of 12Arms, a voltage rating of 240/480 VAC, and an analog connectivity option. The drive can be used with linear motors, induction machines, and synchronous servomotors. It supports various protocols such as HIPERFACE, BiSS, and ENDAT 2.1&2.2. When connecting to the mains power supply ensure to use an ideal fuse and the DC bus link voltage should be 170 to 680 VDC.

The ambient conditions of the AKD-B01207-NBAN-0000 include a vibration class of 3M1 according to IEC 60721-3-3, operating environment of pollution level 2, and vertical mounting orientation. The operating temperature is between 0 and 40 degrees, relative humidity is between 5 and 95%, while the installation elevation is capped at 1000 meters above sea level. The noise emission is 44dB, thermal dissipation at rated current is 153W and the maximum motor induction is 250mH. It features a rated supply voltage of 3 x 240V to 480V +/-10% and a rated supply input frequency of 50 to 400Hz +/-5%.

Only personnel well-versed in handling electrostatically sensitive components should transport, store, install, and test the AKD-B01207-NBAN-0000. Do not use the drive in potentially explosive environments, environments with electrically conductive oils, dust, vapor or acids. Like other AKD drives, it is UL and cUL recognized and conforms to CE and EAC requirements. Mount it in a control cabinet that meets pollution 2 environment requirements.  It comes with a one year warranty.

  • AKDB01207-NBAN-0000
  • AKD-BO12O7-NBAN-OOOO

AKD-B01207-NBAN-0000 Technical Specifications

Control Logic, Supply Voltage: 24 V
Control Logic, Supply Voltage:
Current Loop Bandwidth Max.: 2-3 kHz
Drive Continous Output Power: 8000 Watts
Peak Output Current: 30 A
Rated Output Current: 12 A
Rated Supply Voltage: 240/480 V
Velocity Loop Bandwidth Max.: 0-600 Hz
