The Kollmorgen AKT-AN-400-000 is an analog input module from the AKT IO Terminals series and weighs 75 grams. This module features 4 thermocouple input channels, internal temperature compensation, and a resolution of 0.1 degrees Celsius per digit. It uses a 2-wire connection method, offers wiring fail indication, and is protected with an IP20 rating.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The AKT-AN-400-000 belongs to the AKT IO Terminals series from Kollmorgen and is an analog input module in the Advanced Kollmorgen Terminal family. It accepts temperature signals from industrial thermocouples and forwards digital values through the series backplane so a controller can monitor process heat, cooling loops, or environmental chambers. In decentralized I/O stations, this module occupies minimal panel depth, allowing temperature acquisition to be placed close to the sensor and reducing wiring runs inside automated machines. Placing signal conversion near the sensing point can also help keep low-level thermocouple signals away from longer cabinet runs that may introduce electrical noise.
The module samples up to 4 channels of sensor data, and each channel is a thermocouple input. For accuracy, cold-junction compensation is supported by an onboard sensor that provides internal temperature measurement. Converted values resolve down to 0.1 °C/digit, making the device suitable for fine thermal control tasks. Data for all inputs appears in the controller image as 4 × 16-bit words, so scaling calculations remain consistent across platforms. No manual address wheels are required because slot position alone determines fieldbus mapping.
A typical station budget only allocates 75 mA of load to this unit, drawn from the Standard-Bus supply that powers all AKT terminals. Touch-safe design is shown by the IP20 protection class, and the assembly mass is only 75 g, easing strain on DIN-rail latches. Signal leads clip into push-in blocks and support direct thermocouple wiring without intermediate amplifiers in many applications. The terminal can be mounted horizontally or vertically, and wiring-fault indication reports open circuits to the PLC so control logic can respond to sensor interruptions.
Frequently Asked Questions about AKT-AN-400-000:
Q: How many input channels does the AKT-AN-400-000 provide?
A: The AKT-AN-400-000 terminal supports four thermocouple input channels.
Q: What connection method is used for the AKT-AN-400-000 thermocouple inputs?
A: Thermocouple signals on this terminal are measured using a 2-wire connection method.
Q: Does the AKT-AN-400-000 offer cold junction compensation?
A: The AKT-AN-400-000 features internal temperature measurement for cold junction compensation.
Q: What is the temperature measurement resolution of the AKT-AN-400-000?
A: Resolution for temperature measurement is 0.1 °C per digit on the AKT-AN-400-000.
Q: Does the AKT-AN-400-000 indicate wiring failures?
A: Wiring failures are detected by the AKT-AN-400-000 terminal, thanks to its wiring fail indication feature.
