13.F5.B1D-390A
Wake Industrial LLC is not an authorized distributor of this product.
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
Available
The 13.F5.B1D-390A axis drive includes 12 A current input, a power rating of 5.50 kW, sensorless motor management with KEB-SMM, and a maximum current of 25.9 A. Part of the F5 Combivert Axis Drive Series manufactured by KEB, it features IP 20 enclosure protection and supports short-circuit and earth fault monitoring.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The 13.F5.B1D-390A is manufactured by KEB Automation. KEB produces the 13.F5.B1D-390A axis drive, a high-performance part suited for demanding industrial applications. With a 5.50 kW power rating, this product, which is a member of the F5 Combivert Axis Drive Series, can drive motors that need a lot of power. The drive's power to provide strong performance even under high loads is further shown by its ability to manage a maximum current of 25.9 A. KEB-SMM, a sensorless motor management system, is installed on the 13.F5.B1D-390A. Without the need for external sensors like encoders, this novel feature allows for accurate motor control. By removing the need for extra parts, sensorless motor management helps create a more efficient and economical system design.
The drive is suitable with a variety of industrial power systems since it works within a broad input voltage range of 3-phase 380-480 V AC. This adaptability minimizes the requirement for extra power conditioning equipment by ensuring smooth integration into various operating situations. Programmable digital inputs and outputs as well as programmable analog outputs are among the many input and output choices available on the 13.F5.B1D-390A. These capabilities provide a great deal of customization and integration flexibility with other automation components, enabling effective data exchange and customized control techniques.
The drive's IP 20 enclosure protection, which defends against the entry of solid objects bigger than 12.5 mm and prevents unintentional contact with live components, further strengthens its sturdy construction. In industrial settings where there may be moisture and dust, this degree of protection guarantees dependable performance. Safety features, including short-circuit and ground fault monitoring, are included in the 13.F5.B1D-390A. These features reduce the possibility of damage and guarantee the security of both people and equipment by continually monitoring the electrical system and initiating the proper preventative actions in the case of a malfunction. For the 13.F5.B1D-390A axis drive, Wake Industrial provides a one-year guarantee, giving customers piece of mind and assurance about the product's dependability and longevity.
Frequently Asked Questions about 13.F5.B1D-390A:
Q: What is the power rating of the 13.F5.B1D-390A axis drive?
A: The 13.F5.B1D-390A axis drive has a power rating of 5.50 kW, making it suitable for a range of industrial applications that require high-performance drives.
Q: What kind of motor management technology does the 13.F5.B1D-390A feature?
A: The 13.F5.B1D-390A features sensorless motor management with KEB-SMM technology, which helps in efficient control of the motor without the need for encoders.
Q: What is the input voltage range for the 13.F5.B1D-390A?
A: The input voltage range for this axis drive is 3-phase 380-480 V AC, which makes it compatible with various industrial power systems.
Q: What is the maximum current for the 13.F5.B1D-390A?
A: The maximum current for the 13.F5.B1D-390A is 25.9 A, ensuring it can handle demanding operational conditions.
Q: What is the output frequency of the 13.F5.B1D-390A?
A: The 13.F5.B1D-390A supports an output frequency of up to 400 Hz, which is ideal for high-speed applications.
