Product Description

The 10F4C3D-3460 is a Combivert frequency inverter from KEB Antriebestechnik and has a DC voltage link, along with programmable analog and digital inputs. The drive inverter operates based on the principle of pulse width modulation. It has two analog inputs, one analog output, four digital inputs, and one digital output. Apart from these inputs and outputs, the unit also encompasses eight parameter sets, software inputs and outputs, and two programmable relay outputs.

The inverter supports various functions like jogging (programmable), energy saving, power-off, slip compensation, and DC braking. It has 4.8A input current rating, 460V to 500V input voltage rating, 5.8A output current rating, and 305V to 440V output current rating. The 17KVA output nominal power three-phase inverter operates at 12kHz clocking frequency. The unit weighs 2.63 KG. The control board of the device supports three operating modes - customer mode, application mode, and drive mode. The inverter renders comprehensive password protection option for changing the operating mode, switching to the drive mode, activating the service mode, and setting a write protection. The parameters of the password depend on the mode that the unit is operating in.

The F4 series frequency inverter features 10 housing size and comes along with a D type housing design. The unit incorporates a compact control along with braking transistor and filter accessories. It comprises IP20 degree of protection and works at -10°C to 45°C ambient temperature range. The inverter features maximum 95% relative humidity without condensation. The inverter is intended only for controlling the stepless speed of three-phase AC motors. KEB Antriebestechnik ships the inverter worldwide with a one-year warranty period using multiple delivery channels.
