Product Description:

The VSP40.1BIE-512NN-C1D-AN-NN-FW operator panel is manufactured by Bosch Rexroth Indramat as part of the VSP IndraControl Terminals series. This unit combines an industrial display with an integrated computer so that machine operators can view process data, alarms, and control dialogs directly at the equipment. It serves as a human-machine interface between programmable logic controllers and the machine, supporting parameter entry, status viewing, and diagnostic access during operation.

The front panel includes a 15-inch color TFT display for clear status visualization. Its native resolution of 1024 × 768 px matches common SCADA layouts without scaling. A sealed aluminum bezel with IP65 protection resists dust and low-pressure water jets, and the 407 × 370 mm front dimensions leave room for 16 machine keys for direct command access. Network connectivity is provided through one RJ45 10/100 Base-T interface, while field power is supplied at 24 VDC so the panel can share a standard control power bus. Internally, a Celeron processor running at 2 GHz supports the visualization runtime without requiring a separate computer.

The computing core uses 512 MB of DDR memory, which is suitable for embedded operating systems in industrial control tasks. Expansion is available through 6 PCI slots, allowing additional fieldbus or interface cards to be installed as needed. The front of the unit includes two Type-A USB ports for removable media or peripheral connections, and legacy devices can be connected through a single RS232 serial port. The integrated power supply can deliver 300 W to the motherboard and installed add-on cards. The open chassis has an IP00 enclosure rating, so the panel must be mounted inside a protected electrical cabinet. No optical drive is installed, which reduces moving parts and leaves more internal space for cooling.
