Product Description:

The VPP40.3DGM-1G0NN-D1D-DN-NN-FW is an operator terminal manufactured by Bosch Rexroth Indramat for the VPP IndraLogic Terminals series. It functions as a human-machine interface that links programmable controllers to machine operators, allowing them to issue commands, confirm alarms, and observe process values from a single front panel. It also presents machine status and control prompts in one place, which supports direct interaction at the point of operation.

The visualization hardware centers on a 15 in active-matrix screen that renders graphics at 1024 x 768 pixels. Because the panel uses a TFT module, image contrast and refresh remain stable across a wide viewing angle, and its palette reaches 256,000 colors for detailed mimics and trend curves. A front rating of IP65 blocks dust and low-pressure water jets, so the display can be mounted on enclosures that face washdown areas. An integrated touch layer allows direct interaction without external pointing devices. The keypad also provides 16 machine keys, 16 function keys, and 14 additional keys for tactile operation when gloves are worn. The screen remains readable in ambient temperatures from 5 °C to 45 °C, matching typical control-cabinet conditions, and the panel tolerates vibration up to 1 g during continuous duty.

Control electronics are powered from a regulated 24 V DC supply, simplifying integration with low-voltage machine wiring. The housing stands 370 mm high and 407 mm wide, so it fits cutouts common to mid-size operator stations while leaving space for cable routing behind the bezel. Mechanical durability is confirmed by a shock resistance of 15 g, allowing the terminal to withstand incidental impacts during transport or service. Touch capability is provided as standard, and shock-mounted internal components help the unit maintain its vibration limit during continuous operation.
