Product Description:

The VPP40.3DFL-2G0NN-D4D-HN-NN-FW IndraLogic Terminal is an operator panel computer produced by Bosch Rexroth Indramat within the VPP IndraLogic Terminals series. The unit combines an industrial PC, a 15-inch touchscreen, and membrane keys so that machinery status can be viewed and commands issued directly on the factory floor. It serves as the central user interface for PLC-controlled cells, allowing visualization, parameter entry, and diagnostic access through one integrated device.

Processing hardware supports interface performance. A Core i5-520M processor operates at 2.4 GHz, giving dual-core computing power for local logic execution and visualization tasks. The panel carries 2 GB RAM, which is adequate for HMI runtimes and motion libraries, and a 192 GB SSD that stores the operating system, project files, and log data with solid-state shock resistance. Graphics are rendered at 1024 × 768 pixels on the 38.1 cm TFT screen, providing clear process graphics and trend curves. The foil-key and touchscreen combination allows both glove-friendly hard keys and direct touch navigation without external pointing devices.

The hardware profile also includes expansion, enclosure, and power details. The unit provides 2 × PCI slots for expansion, enabling optional fieldbus or specialty I/O cards while staying within the 407 mm width, 370 mm height, and 135 mm depth envelope. The aluminum bezel carries a front rating of IP65, so splashing fluids or dust do not reach the electronics, while the rear area is limited to IP20 for cabinet airflow. The system draws 160 W at full load from a regulated 24 V DC supply, allowing the use of compact power sources and UPS modules. Passive cooling through the metal rear panel avoids fans, and the sealed touch-foil face maintains its protection after repeated key actuations.
