Product Description:

The VPP16.3DBM-1G0NN-D1D-DN-NN-FW is a human-machine interface panel manufactured by Bosch Rexroth Indramat as part of the VPP IndraLogic Terminals series. It acts as the operator front end for programmable controllers, allowing operators to issue commands, view process variables, and acknowledge alarms directly at the machine. The terminal integrates display hardware, touch input, and communication ports to simplify cabinet wiring and support local machine control.

Beneath its TFT display, the panel renders up to 256,000 colors at a native resolution of 800 x 600, providing clear graphics for visualization objects. The screen diagonal of 30.5 cm (12") provides enough area for multiple pop-up windows while maintaining a compact enclosure. Two Ethernet TCP/IP ports allow separate connections for controller traffic and plant networks, and the touch surface responds to finger or stylus input so external keys are unnecessary. A front USB connector provides convenient access for data transfer, six rear USB 2.0 ports support peripherals, and a VGA output can drive an auxiliary monitor. The unit accepts a control cabinet supply of 24 V DC, keeping its internal power domain within the 30 V SELV limit common in industrial equipment.

For enclosure integrity, the aluminum bezel carries an IP65 rating that resists dust ingress and low-pressure water jets, while the rear housing is intended for cabinet interiors where open slots meet IP20 requirements. The panel withstands continuous vibration loads of 1 g and survives transport shocks up to 15 g, so it can be mounted on moving gantries or press lines without display damage. Electrical losses cap its consumption at 160 W, and this thermal load can usually be managed by forced cabinet airflow. Overall dimensions of 350 mm in width and 290 mm in height allow the terminal to fit standard door cutouts while leaving clearance for access around the installation area.
