Product Description:

The VPP15.3GAK-4G0NN-D5D-HN-NN-FW is an operator interface terminal produced by Bosch Rexroth Indramat for the VPP IndraLogic Terminals series. As a panel-mounted PC, it provides local visualization, data processing, and touch interaction at the machine frame, removing the need for an external industrial computer. The unit links control logic with operator input, allowing commands, status screens, and alarm acknowledgments to be handled directly from the enclosure door on automated packaging, material-handling, or machining lines.

Inside the housing, a Core i7-620M, 2.66 GHz processor executes the IndraLogic runtime and SCADA tasks, while 4 GB RAM provides volatile memory for program variables, trending buffers, and operating system functions. Non-volatile data, such as recipe sets and system images, are stored on a 192 GB SSD, which supports fast boot cycles and resists vibration better than rotating media. Operators view the process through a 15.6 in TFT panel that reproduces up to 16 million colors at 1366 × 768 resolution, providing clear graphics and readable alarm symbols. The LED-backlit screen works with a projected-capacitive sensor for multi-finger gestures, while dual Ethernet ports support simultaneous connections to the machine network and plant MES servers. Six USB 2.0 receptacles accept service media, barcode readers, or keyboards, and the single PCI slot leaves room for a fieldbus or motion control card.

Power is supplied at 24 V DC, and the electronics draw no more than 160 W, which is compatible with standard cabinet power supplies. The aluminum bezel provides IP65 protection on the front face, helping block dust and low-pressure water jets, while the rear panel is rated IP20 for installation inside protected enclosures. Its projected-capacitive surface recognizes Multi-Touch commands through thin safety glass, and the enclosure weighs 6.8 kg to support panel installation during retrofit work.
