The Bosch Rexroth Indramat VPB40.3D1L-2G0NN-D2D-HN-NN-FW is part of the VPB IndraControl PC Units series and uses a Core 2 Duo T7400 processor with a 2.16 GHz clock and 4 MB of L2 cache. It features two PCI slots with 180 mm max card length, 2048 MB of memory, and a minimum 100 GB 2.5 inch SSD for storage. The unit operates on 24 V DC supply voltage and provides 6 USB Type A ports, 2 Ethernet RJ45 ports, and an IP20 protection rating.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VPB40.3D1L-2G0NN-D2D-HN-NN-FW is an industrial PC unit built by Bosch Rexroth Indramat for the VPB IndraControl PC Units series. Mounted in a machine cabinet, it serves as the central processor for automation tasks and communicates with an IndraControl operator panel through the CDI interface. Its purpose is to execute real-time control software, coordinate fieldbus traffic, and present HMI graphics. This arrangement allows one cabinet-mounted unit to support both control and visualization functions. By separating the PC from the operator panel, the cabinet installation helps protect the computing hardware from direct contact on the machine front.
Processing capability comes from an Intel Core 2 Duo T7400 operating at 2.16 GHz. The dual-core processor shares a 4 MB L2 cache, which helps it handle task changes and screen updates without unnecessary delay. System memory includes 2048 MB of DDR2 for application data, operating system services, and runtime buffers. The front panel provides 6 USB Type A ports for external storage devices, barcode readers, or other peripherals. Digital video is available through one DVI port, and dual RJ45 sockets connect the controller to plant Ethernet networks. The Intel 82945GME GMCH manages graphics and memory functions, while the Intel 82801GHM I/O controller supports peripheral timing. Two internal PCI sockets accept option cards up to 180 mm long, so additional motion or fieldbus interfaces can be installed within the enclosure depth.
Mass storage is provided by a 2.5 in SSD with at least 100 GB of capacity for the operating system, recipes, archives, and log files. All electronics run from a single DC 24 V supply connected through a cabinet terminal strip. The housing has an IP20 rating, so the PC is intended for use inside a closed electrical enclosure. Solid-state storage also avoids rotating media, which helps the unit tolerate vibration better than a conventional hard drive during continuous machine operation. The terminal-strip power input also matches the low-voltage distribution commonly used in control cabinets, which supports straightforward integration with other automation electronics.
Frequently Asked Questions about VPB40.3D1L-2G0NN-D2D-HN-NN-FW:
Q: What processor is used in the VPB40.3D1L-2G0NN-D2D-HN-NN-FW unit?
A: The VPB40.3D1L-2G0NN-D2D-HN-NN-FW is equipped with a Core 2 Duo T7400 processor clocked at 2.16 GHz.
Q: What type and minimum capacity of storage does the VPB40.3D1L-2G0NN-D2D-HN-NN-FW offer?
A: This model comes with a minimum of 100 GB 2.5 inch SSD for storage, providing solid-state data reliability.
Q: How many USB ports are present on the VPB40.3D1L-2G0NN-D2D-HN-NN-FW?
A: There are 6 USB Type A ports available on this unit for peripheral connections.
Q: How many PCI slots are available and what is the maximum supported PCI card length for the VPB40.3D1L-2G0NN-D2D-HN-NN-FW?
A: The device supports two PCI slots with a maximum card length of 180 mm, enhancing expansion capabilities.
Q: What protection rating is provided by the VPB40.3D1L-2G0NN-D2D-HN-NN-FW?
A: This model is rated with IP20 protection, suitable for installation in non-dusty indoor environments.
