Product Description:

The VPB40.3D1L-2G0NN-C3D-DN-NN-FW is an industrial PC unit manufactured by Bosch Rexroth Indramat within the VPB IndraControl PC Units series. Mounted close to servo drives or inside control cabinets, it serves as the processing platform for machine sequencing, visualization, and real-time communication in factory automation cells. Its compact cabinet-mounted design allows control, display, and communication functions to be handled from one integrated computing platform.

It is driven by a Celeron P4500 1.86 GHz dual-core processor that provides the computational bandwidth for PLC and motion kernels while keeping thermal output compatible with fanless cabinet cooling. System memory is 2 GB of DDR3 RAM, allowing local buffering of recipes and diagnostic logs without excessive swap activity. Non-volatile data are stored on a 320 GB HDD, giving adequate capacity for operating system files, application images, and archived trend data. Two gigabit lines on the 2 × Ethernet TCP/IP (1 Gbit/s) interface link the controller to plant networks and drive-based SERCOS gateways, and the front panel offers 6 × USB 2.0 for service sticks, scanners, or touch panels. Input power is accepted through a 24 V DC supply rail, and additional fieldbus or I/O boards can be inserted in the two PCI expansion slots. A single DVI port presents graphics to remote IndraControl multi-touch displays, while a CDI serial port supports legacy peripherals.

Its maximum electrical load is 160 W, so cabinet power budgeting must allocate adequate current on the stabilized 24 V bus. During transport or installation, the chassis withstands mechanical shocks up to 15 g, supporting use on mobile or vibration-prone equipment. Once wired, the electronics are guarded by an IP20 enclosure that limits finger contact and falling debris but relies on the cabinet for higher ingress protection. The housing measures 205 mm in height, 181 mm in length, and 110 mm in width, and the assembled weight is 2.6 kg, enabling direct DIN-rail or plate mounting without heavy supports.
