VAK40.1E-EN-P-MPNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911311207
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat VAK40.1E-EN-P-MPNN is part of the VAK Industrial Keyboards series and features 86 keys with three LED status displays. This keyboard has a protection rating of IP65 and dimensions of 407 mm by 88 mm on the front. It operates on a 5 volt supply voltage with a current consumption of 30 mA, and functions within a temperature range of 5 to 45 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VAK40.1E-EN-P-MPNN is an industrial keyboard produced by Bosch Rexroth Indramat for the VAK Industrial Keyboards series. It serves as a human-machine input component, giving operators direct key access to automation controllers and visualization stations on the plant floor. The unit is designed for panel mounting where compact dimensions and sealed construction are required in production, packaging, and material-handling systems. Its integrated layout also suits control stations where a separate external keyboard would take up unnecessary space or be harder to protect from dust and splash exposure.
The keyboard face spans 407 mm in width and is 88 mm tall, allowing it to fit into standardized rack and cabinet cutouts without occupying excessive fascia space. A matrix of 86 keys supplies alphanumeric entry plus function commands that can be mapped by the control software. Logic electronics are powered from a 5 V ±5% supply rail taken from the host terminal, and total draw is limited to 30 mA, which minimizes load on the system’s low-voltage bus. The enclosure has an IP65 rating at the front, so dust and water jets cannot penetrate the membrane switch area. Three discrete status indications are shown through 3 LEDs, giving immediate visual confirmation of power, communication, or fault states. The pollution degree 2 classification means the keyboard is intended for environments where only non-conductive contamination is expected during service.
The thermal design maintains full functionality between +5 °C and +45 °C, and the electronics are protected against condensation by a maximum temperature gradient of 3 K per minute. When shipped or stored, the assembly tolerates ambient lows down to −20 °C and highs up to +60 °C, which helps prevent damage during transport or warehouse storage. The controlled temperature ramp helps limit moisture formation inside the unit when it is moved from a cool area into a warmer enclosure.
Frequently Asked Questions about VAK40.1E-EN-P-MPNN:
Q: How many keys are available on the VAK40.1E-EN-P-MPNN keyboard?
A: The VAK40.1E-EN-P-MPNN keyboard features 86 keys on its front panel.
Q: What is the protection rating for the VAK40.1E-EN-P-MPNN keyboard?
A: This keyboard has a protection rating of IP 65, making it highly resistant to dust and low-pressure water jets.
Q: What supply voltage does the VAK40.1E-EN-P-MPNN keyboard require?
A: The power supply specification for this keyboard is 5 V with a tolerance of ±5%.
Q: What is the current consumption of the VAK40.1E-EN-P-MPNN keyboard?
A: Maximum current consumption for the VAK40.1E-EN-P-MPNN is 30 mA during operation.
Q: How does the VAK40.1E-EN-P-MPNN keyboard provide status feedback?
A: There are 3 LED status displays built into the VAK40.1E-EN-P-MPNN for system feedback.
