RZE01.2-5-007 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911201248
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat RZE01.2-5-007 is an EMC-filter from the RZE EMC Filters series, featuring a design version 2 and an integrated line configuration. This model supports a line current of 20 Amps, operates at 50 or 60 Hz, and is designed for a maximum line voltage of 3 x AC 500 V. It has a protection class of IP20, a rated power of 7.5 kW for the frequency converter, and weighs 4.4 kilograms.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The RZE01.2-5-007 is an EMC filter produced by Bosch Rexroth Indramat within the RZE EMC Filters series. Installed between the plant mains and a matched frequency converter, the unit attenuates conducted emissions so adjacent automation equipment can operate without electromagnetic interference. It is used on the input side of a drive system, where it reduces high-frequency noise returning to the supply network and helps protect nearby control devices from interference. As a passive filter, it is intended for panel-mounted industrial environments where compliance with harmonic and radio frequency regulations is required.
The filter carries a protection rating of IP20, meaning live parts are finger-safe, but the housing is not sealed against liquids. It is tuned for grids operating at 50 / 60 Hz, allowing use on standard utility supplies worldwide. A continuous line current of 20 A can flow through the device without saturation, which matches the load drawn by a converter in this class. The maximum line voltage is 3 × AC 500 V ±10 %, which supports typical 400 V three-phase systems while tolerating normal mains variation. The filter is intended for converters rated at 7.5 kW, and its internal components help limit differential-mode and common-mode noise produced by drives in that power class.
The maximum ambient temperature is 40 °C, so cabinet airflow or derating is required if this limit is exceeded. The hardware belongs to Size class A, which uses a standardized footprint within the series. Its footprint makes it easier to place beside compatible drive hardware in control cabinets with limited mounting space. The unit has a weight of 4.4 kg, which affects panel loading and mounting support. The product is released as Design Version 2.
Frequently Asked Questions about RZE01.2-5-007:
Q: What is the maximum line voltage supported by the RZE01.2-5-007 filter?
A: The RZE01.2-5-007 filter supports a maximum line voltage of 3 x AC 500 V with a 10% tolerance.
Q: What is the maximum line current that the RZE01.2-5-007 can handle?
A: This EMC filter is designed for line currents up to 20 A.
Q: What rated power of frequency converter is the RZE01.2-5-007 compatible with?
A: The RZE01.2-5-007 is rated for use with frequency converters up to 7.5 kW.
Q: What operating frequencies does the RZE01.2-5-007 support?
A: This filter operates at power frequencies of 50 Hz or 60 Hz.
Q: What is the protection class of the RZE01.2-5-007 EMC filter?
A: The protection class for this filter is IP20, providing solid object protection but not water resistance.
