RKL4323 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN:
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 3-5 Days
The Bosch Rexroth Indramat RKL4323 is part of the RKL Motor Power Cables series and features a cable diameter of 18.5 mm with a PUR jacket in RAL 2003 orange. This cable supports up to 5,000,000 bending cycles, has a power wire cross-section of 6.0 mm², and uses RLS0721/K06 and RLS1301/C06 connectors on the controller and motor sides.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The RKL4323 motor power cable is supplied by Bosch Rexroth Indramat within the RKL Motor Power Cables series. Designed for servo drive installations, the assembly transfers three-phase power from a controller cabinet to a Rexroth motor while tolerating continuous motion inside cable tracks. Its mechanical and electrical properties make it suitable for high-cycle pick-and-place stations, gantry axes, and other factory-automation zones where dependable energy delivery under constant flexing is critical.
The cable core is engineered for durability, surviving up to 5,000,000 bending cycles in drag-chain service without conductor fracture. Installation rules specify a fixed bending radius of 5xD, while dynamic routing must observe 7.5xD to prevent jacket fatigue; both values relate to the external diameter. That diameter measures 18.5 mm, combining individually insulated power leads and an overall PUR jacket that resists oils, coolants, and weld spatter. Together these mechanical limits define clear routing envelopes and ensure service life in fast-moving machine modules.
Electrical behavior is optimized for low losses and stable drive operation. The copper conductors exhibit a resistance of 3.30 Ω/km at 20 °C, limiting voltage drop over typical machine lengths. A distributed capacitance of 0.8 nF/m minimizes reactive current spikes when the inverter switches at high PWM frequencies. Each phase conductor presents a cross-section of 6.0 mm², supporting the continuous motor current specified for the compatible Rexroth drives. On the motor end, the shielded plug coded RLS1301/C06 mates directly with MSK and MAD motors, shortening commissioning time and eliminating wiring errors.
Wake Industrial offers same-day shipping on this cable for facilities that must restore motion quickly. International shipping options are also available to support plants outside North America. To aid budgeting, quotations issued for the RKL4323 remain valid for 30 days.
Frequently Asked Questions about RKL4323:
Q: What is the maximum number of bending cycles the RKL4323 cable can handle?
A: The RKL4323 cable is designed to withstand 5,000,000 bending cycles for long-lasting flexibility.
Q: Which connector is provided on the controller side of the RKL4323 cable?
A: The controller-side of the RKL4323 uses the RLS0721/K06 connector.
Q: What is the jacket color of the Bosch Rexroth Indramat RKL4323 cable?
A: The jacket color of the RKL4323 cable is RAL 2003 orange for easy identification.
Q: What is the discharge capacitance rating of the RKL4323 cable?
A: The discharge capacitance of the RKL4323 cable is 0.8 nF per meter.
Q: What is the power wire cross-section size of the RKL4323 cable?
A: The power wires in the RKL4323 cable have a cross-section of 6.0 mm² for efficient power transmission.
