RKG0022 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN:
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
Available
Current response time:
5 Minutes
55 Seconds
The Bosch Rexroth Indramat RKG0022 is an encoder cable from the RKG Encoder Cables series designed for drag chain use and rated for 5,000,000 bending cycles. It features a PUR jacket in RAL 2003 color, with a cable outer diameter of 8.8 mm and supports an operating control voltage of 300 V. The cable uses an INS0760/C01 D-Sub 15 pin controller connector and an INS0672/C01 clamp terminal 10 pin motor-side connector.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The RKG0022 encoder cable is produced by Bosch Rexroth Indramat as part of the RKG Encoder Cables series. It links Indramat motors that have integrated measuring systems to the digital drive controller, carrying position feedback and auxiliary control lines for closed-loop operation. The assembly is supplied as a ready-made harness with factory-installed connectors on both ends, reducing commissioning time and ensuring shielding and pin assignments are preserved in automated machining centres, material-handling gantries, and other motion axes.
The mechanical profile prioritises long service life in constantly moving carriers. It withstands 5000000 bending cycles, enabling multi-shift operation in high-speed drag chains. The overall diameter of 8.8 mm supports small bend radii while keeping the cable bundle compact inside energy tracks. Each control core uses a conductor cross-section of 0.25 mm², providing sufficient current for encoder supply without adding excess stiffness. At the controller, feedback lines terminate in a D-Sub 15 Pin interface seated in the INS0760/C01 shell, giving direct compatibility with Indramat drive cards and removing the need for intermediate terminal blocks. Drag chain use is explicitly permitted, and the outer sheath resists machining oils.
Electrical insulation on the control conductors is rated for 300 V, so the cable can be routed alongside low-power I/O lines inside shared carriers without derating. The sheath is coloured RAL 2003 for fast identification during maintenance, and the tough PUR compound maintains flexibility over a wide temperature range while resisting abrasion. Motor-end conductors land on a Clamp Terminal 10 Pin block housed in the INS0672/C01 receptacle, securing each core without soldering. Internal layer design and conductor spacing follow the INK0448 bulk cable specification, allowing on-site extension or repair with standard reel material while keeping impedance consistent with the original assembly.
Frequently Asked Questions about RKG0022:
Q: How many bending cycles can the RKG0022 encoder cable withstand?
A: The RKG0022 encoder cable supports up to 5,000,000 bending cycles for long-lasting drag chain use.
Q: What type of controller connector does the RKG0022 cable use?
A: The controller connector on the RKG0022 is a D-Sub 15 pin type, model INS0760/C01.
Q: What jacket material and color does the RKG0022 encoder cable have?
A: This cable features a PUR polyurethane outer jacket in RAL 2003 color.
Q: What is the type of bulk cable in the RKG0022 encoder cable?
A: The bulk cable used in the RKG0022 is INK0448, designed for encoder applications.
Q: What is the control wire cross-section of the RKG0022 encoder cable?
A: The RKG0022 supports a control wire cross-section of 0.25 mm² for its signal transmission.
