Product Description:

The RD52.1-4N-037-L-V1-FW is a drive controller from Bosch Rexroth Indramat in the RD 500 Drive Controllers series. It supervises three-phase induction or synchronous motors in automated machines by converting fixed-frequency line power into regulated output that matches commanded torque and speed profiles. The controller is well suited to equipment that requires repeatable motor response during starting, load changes, and deceleration. Within an automation cell, the unit coordinates motor current and motion so conveyors, pumps, or processing axes follow programmed cycles with minimal overshoot and energy loss.

This controller delivers a rated output of 37 kW, giving it enough capacity for midsize production spindles and high-inertia loads. It is designed for supply networks from 380 to 480 V and accepts line variations of up to ±10 % without derating. Incoming power passes through a three-phase AC converter bridge, and the internal current regulators use field-oriented vector control to maintain precise flux alignment during dynamic acceleration and braking. This control method helps the drive maintain stable torque response when mechanical demand changes abruptly, and it supports accurate speed holding across normal operating conditions.

Thermal management is handled by forced air cooling, so cabinet airflow must be maintained to carry heat away from the heat sink channels. Line-side electromagnetic interference is reduced by an integrated line filter, which helps limit the need for external filtering components. Because the unit is supplied without a built-in brake chopper, dynamic braking energy must be dissipated through an external resistor or returned to the supply network, and braking arrangements must be provided at the system level when frequent deceleration is expected. Control electronics can remain active during power interruptions through 24 V standby power, which supports communication and parameter retention. The unit is a generation 1 design.
