RD51.1-4N-015-L-D1-FW
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911200550
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The RD51.1-4N-015-L-D1-FW drive controller features a rated power of 15 kW, an input voltage of 3 x 380...480 V AC with ~10% tolerance, an enclosure type of IP20, and internal fan cooling. Part of the RD 500 Drive Controllers series by Bosch Rexroth Indramat, it supports vector control and offers communication interfaces like CANopen.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The RD51.1-4N-015-L-D1-FW is a state-of-the-art controller manufactured by Bosch Rexroth Indramat to provide customers with a product that is flexible enough to be used for the universal control of various motor designs including synchronous, and induction motors. This control device has several characteristics that make it appropriate for industrial applications. Some of these features include its removable user panel with parameter copy function, peer-to-peer coupling support, and its compatibility with several connection interfaces. The nominal connecting voltage required by the RD51.1-4N-015-L-D1-FW is between 380 to 480 volts, the controller also has a rated power data of about 15 kilowatts. There is a brake chopper built into this product; this chopper helps the controller to handle the excess heat produced by connected motors during deceleration.
The RD51.1-4N-015-L-D1-FW industrial controllers are equipped with an internal air blower that gets rid of excess heat through forced ventilation. The firmware suitable for this product is not included in its delivery package; it is a separate component that has to be independently ordered by operators. Their recommended environmental class for this product is 3K3 according to DIN IEC 721-3-3, its noise immunity level is also class A1 as defined by EN 55011.
The housing of the RD51.1-4N-015-L-D1-FW is built from strong metallic material and is able to provide protection according to IP20; however, there is still a need for the motor to be installed inside a control cabinet that provide minimum protection that meets IP54. The total weight of this product is about 11.3 kilowatts. The recommended ambient temperature for this device is between 0 to 40 degrees, Installation altitude is also advised to be maintained below 1000 meters for operation without the risk of derating.
Frequently Asked Questions about RD51.1-4N-015-L-D1-FW:
Q: How can operators adapt motors to the RD51.1-4N-015-L-D1-FW after connection?
A: The Automotive motor adaptation with parameter identification occurs as soon as the motor is connected.
Q: What is the cooling mechanism of the RD51.1-4N-015-L-D1-FW?
A: This controller contains an internal air blower responsible for its cooling during operation.
Q: Is the RD51.1-4N-015-L-D1-FW equipped with a display unit?
A: Yes. There is a small connection panel with a display unit and pressure sensitive keys attached to this product.
Q: Is the RD51.1-4N-015-L-D1-FW an IP20 device?
A: Yes. This controller unit requires installation into an control cabinet for additional protection.
Q: What is the peak installation height for this product?
A: For operation without derating, the RD51.1-4N-015-L-D1-FW should not be installed an used at an altitude higher than 12 millimeters.
