RAC 2.2-200-460-L00-W1
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911254588
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
Available
RAC Spindle Drive is manufactured by Bosch Rexroth Indramat. This drive has a current type of 300 A and a speed set of 10V. This drive also contains connecting terminals X4 and a connection voltage of 460V.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The RAC 2.2-200-460-L00-W1 is a main spindle drive controller. It is a mechanical device produced by Indramat that provides intelligent digital control of Indramat 2AD asynchronous main spindle motors and 1MB frameless spindle motor. It has a continuous motor output of 30kW to 52kW at the drive shaft of the motor. It has a protection level standard of IP 100 according to EN 60529 (DIN VDE 0470).
The type code of the RAC 2.2-200-460-L00-W1 indicates that its type current is 300A. It uses a SERCOS Interface as a speed set point. Designed without any additional encoder input, interface or bleeder, it comes with a standard built-in fan for cooling. In reference to cooling and environment its permanent humidity is F according to DIN 40 040. The controllers of the RAC 2.2-200-460-L00-W1 weigh 121kg, the mounting frame (M1-RAC4) weighs 2kg and other accessories like the M2-RAC weighs 1.7kg. The electrical designations like the continuous controller output is 55kW which is the same as the peak controller output. The rated connection voltage is 3×AC 400V, 50Hz ± 15% or alternatively 3×AC 460V, 60Hz ± 10%. The continuous regeneration output is 37kW and peak regeneration output at a Maximum of 5 seconds is 55kW.
While setting it up height should not exceed 1000m above sea level if rated data is not reduced. Its permanent ambient temperature which is in range with rated data is 5°C to 45°C. If rated data is reduced to 80% then permanent ambient temperature will increase to 55°C. Storage and transport temperature remains within the confines of -30°C to 85°C. The RAC 2.2-200-460-L00-W1 comes in a transport delivery container with its accessories placed in plastic bags. There is a guarantee that the current and insulation grades have been vetted in accordance with VDE 0160. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
