PPC-R22.1N-T-Q2-P2-NN-FW

  • Rated 4.7 (38 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911309368
    In-Stock, Ships 3-7 Days
  • Call for Expedited Shipping and Product Condition Options

The PPC-R22.1N-T-Q2-P2-NN-FW is a best-in-class motion control unit designed by Bosch Rexroth Indramat. The device does not have a memory expansion module. Its ambient operating temperature is 0 to 45 °C. The product is compact in size and weighs 1.3 kg.

✓ In-Stock!

Wake Industrial LLC is not an authorized distributor of this product.

PPC-R22.1N-T-Q2-P2-NN-FW

  • Rated 4.7 (38 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911309368
    In-Stock, Ships 3-7 Days
  • Call for Expedited Shipping and Product Condition Options

The PPC-R22.1N-T-Q2-P2-NN-FW is a best-in-class motion control unit designed by Bosch Rexroth Indramat. The device does not have a memory expansion module. Its ambient operating temperature is 0 to 45 °C. The product is compact in size and weighs 1.3 kg.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The PPC-R22.1N-T-Q2-P2-NN-FW is a RECO CNC module from Bosch Rexroth. This module has a design code of 2. Its power supply connection makes use of a cable with a 0.75mm2 to 1.5mm2 cross-section based on current requirements. The product is likely to have a high discharge current and high voltage during operation. The device must be installed only in commercial machinery. It should be started only if the machine that it is installed on, adheres to the national standards and regulations on safety, as well as other safety specifications. The module must be operated and repaired only by qualified and trained staff.

The safety conductor of the CNC module should always be firmly and permanently connected to the supply mains. The housing of the product becomes very hot while operating and must not be touched to avoid burns. The emergency stop switch must be mounted in a position that can easily be accessed by the operator. The device should not be disassembled or opened in a pressurized state. The unit features an H1 LED display at its top. Its module rack cannot be used to control I/O modules. The product must be installed only after the module rack is mounted.

The module rack should be engaged on a DIN TS top hat rail of size 35 x 27 x 15mm and secured in position with a locking screw. The CNC module weighs 1.3kg. The device functions between a temperature range of 0°C and +45°C without reduced performance. The 24VDC power supply has a tolerance limit of -15% or +20% according to EN 61131-2 specifications. The product features one ready-for-operation relay to assist in system monitoring. The relay has a minimum lifetime of 500,000 switch cycles when it is protected against excess current. The module can be shipped with a warranty of one year to your preferred address.

  • PPCR22.1N-T-Q2-P2-NN-FW
  • PPCR22.1NTQ2P2NNFW
  • PPC R22.1N T Q2 P2 NN FW

PPC-R22.1N-T-Q2-P2-NN-FW Technical Specifications

Permissible Range: 19.2 ... 30 VDC (ripple factor included)
Rated Value: 24 VDC
Tolerance: -15% / +20% (according to EN61131-2 1994)
