Product Description

The MSK series of motors is one of the synchronous servo motor series in the Rexroth IndraDrive drive system by Bosch Rexroth. They are a class of servo motors under the IndraDyn S family and display a high torque density and broad power spectrum. Their most popular applications are seen in machine tools, printing and paper-processing machines, and packaging and food-processing machines.

The MSK060C-0600-NN-S2-UG0-RNNN is a model of the IndraDyn S MSK servo motor series designed and manufactured by Bosch Rexroth. It has a frame size of 060 and a frame length C with a maximum torque of 24.0Nm. The top speed of this motor is 6,000 rpm and the moment of inertia of its rotor is 0.00080 kgm². Its motor encoder system is the integrated single-turn absolute encoder with EnDat 2.1 interface, which uses the optical method to determine the motor speed and position. It eliminates the need for a separate incremental encoder while permitting the recording of the absolute, indirect position of the motor within one mechanical motor rotation.

The cooling of the MSK060C-0600-NN-S2-UG0-RNNN is by natural convection. Because of this cooling mechanism, the motor is called a self-cooling motor. The heat generated in the machine is dissipated to the ambient air through convection and to the machine construction by conduction. Its Ingress Protection rating is IP 65 according to IEC 60529; hence no solid extrinsic objects can penetrate it to cause damage. The motor is also protected against damage by water jets. Its housing is coated in a black (RAL9005) 2K epoxy resin coating, which is completely resistant to diluted acids/alkaline solutions, seawater, sewage, and current mineral oils.
