The Bosch Rexroth Indramat MKE118B-024-CG0-KE6 is a servo motor from the MKE Synchronous Motors series designed for potentially explosive areas, compliant with ATEX standards. It provides a continuous current at standstill of 15.3 A, a maximum torque of 102.0 Nm, and a shaft with a DIN 332 'DS' thread and shaft seal. The motor has an optical multiturn absolute Hiperface encoder and weighs 45 kg without a holding brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKE118B-024-CG0-KE6 is a servo motor manufactured by Bosch Rexroth Indramat and assigned to the MKE Synchronous Motors series. It is intended for motion tasks in potentially explosive atmospheres, and its housing follows ATEX requirements so the motor can be mounted in hazardous-area drives without additional mechanical protection. It converts electrical energy into controlled rotary motion for machinery that requires flame-proof construction.
When the connections exit upward through a terminal box, the unit can deliver a continuous standstill torque of 28.0 Nm while drawing a continuous standstill current of 15.3 A. During acceleration or short overloads, it can reach a maximum torque of 102.0 Nm and a peak current of 69.1 A. A top speed of 4000 rpm allows coordinated motion cycles in packaging, printing, or material-handling axes. Operation is permitted from 0 °C to +40 °C, and insulation class 155 (F) supports the associated thermal rise. The 024 winding has an inductance of 0.580 mH, a resistance of 7.60 Ω at 20 °C, and a discharge capacitance of 10.3 nF. Feedback is supplied by an optical multi-turn absolute Hiperface encoder, model M1, with 128 increments per revolution, providing position data after power loss. Cable glands from 17 mm to 19.5 mm seal the terminal box, and the plain shaft has a front centering hole and a DIN 332 DS thread. The motor is built without a holding brake, includes a shaft seal to limit ingress, and has a sound pressure level of 61.1 dB(A).
A rotor moment of inertia of 0.01940 kg·m² supports a balance between dynamic response and smoother load coupling. The electromagnetic design yields a torque constant of 2.12 Nm/A and a back-EMF constant of 130.0 V per 1000 rpm for predictable drive matching. Component mass is 45.0 kg, so the mounting structure must support that static load.
Frequently Asked Questions about MKE118B-024-CG0-KE6:
Q: Does the MKE118B-024-CG0-KE6 motor include a holding brake?
A: This model is manufactured without a holding brake.
Q: What encoder type is used in the MKE118B-024-CG0-KE6 motor?
A: The MKE118B-024-CG0-KE6 features an optical multiturn absolute Hiperface encoder.
Q: Is the MKE118B-024-CG0-KE6 motor suitable for explosive environments?
A: This motor is compliant with the ATEX housing standard for potentially explosive areas.
Q: What shaft features are provided with the MKE118B-024-CG0-KE6?
A: The plain shaft on this model is detailed with a frontal centering hole and a DIN 332 compliant 'DS' thread.
Q: What is the continuous standstill torque of the MKE118B-024-CG0-KE6 motor?
A: The continuous standstill torque at 60K is rated at 28.0 Nm for this model.
