Product Description:

The MKE096B-047-PP0-KN is a three-phase AC servo motor in the MKE Synchronous Motors series from Bosch Rexroth Indramat. It is intended for precise position and speed control on machinery installed in hazardous zones, where flame-proof housings and certified feedback systems are required. Within an automation cell, the motor couples directly to a drive controller and converts commanded current into torque for conveyor indexing, pick-and-place axes, and other coordinated motion tasks. Its design supports applications that require accurate rotary movement while maintaining the protective features needed for classified operating areas.

The electrical interface is oriented upward because the connection direction is top, so power and feedback cables can exit without additional 90-degree adapters. Conductors terminate inside a terminal box that provides threaded glands and ample space for shield termination, which helps support electromagnetic compatibility requirements. The stator uses winding code 047, which sets the base voltage constant and current requirement expected by the matching drive. Motion is stopped exclusively by controlled torque because the unit is delivered without a holding brake, which removes residual drag in continuous-rotation applications. To protect the internal bearing grease from dust and oil mist, a shaft seal is fitted at the output end.

This model is qualified for use in potentially explosive areas, meaning its surface temperatures and clearances meet the ignition-risk limits for designated zone categories. Mechanical power is transmitted through a shaft with keyway, allowing rigid coupling to pulleys or gear hubs while preventing slip under cyclic loads. The key geometry follows the DIN 6885 profile, so standard machine keys can be used without modification. Dimensional tolerances, material selections, and safety certifications follow the requirements of this motor series.
