MKD112D-027-GP0-AN

  • Rated 4.6 (29 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911283189
    In-Stock, Ships 3-5 Days
  • Unused Original Box Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options

The MKD112D-027-GP0-AN servomotor offers a power rating of 16 kW, a maximum speed of 6000 RPM, a torque rating of 75 Nm, and a weight of 45 Kg. Part of the MKD Series manufactured by Bosch Rexroth Indramat, this motor features IP65 protection and uses an incremental encoder with 2500 lines for feedback.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth prides itself on its large client base, thanks to its wide array of designs and integrated systems. Having been in the industry for over 60 years, Bosch Rexroth understands the needs of its clients so that it manufactures powerful, future proof and unique products. Some of Bosch Rexroth’s high-quality products include the mains filters, servo motors, drive controllers, synchronous motors, spindle drives, asynchronous motors, low inertia motors, and Rexroth shielded cables.

The MKD112D-027-GP0-AN synchronous motor needs particular parameter values for optimal performance. To maintain the ideal temperature, there are natural and surface cooling options. In surface cooling, the overtemperature is 60K/100K while in natural cooling, it is either 60K or 100K. The rated data parameters are as follows: the rated speed is 2000 min-1 and the rated frequency is 133 Hz. At 60K overtemperature, the rated torque is 27.3 Nm, the rated current is 12.7 Amps, the rated performance is 6.9 kW and the rated voltage is 331V. In 100K overtemperature, the rated voltage stands at 331 V, the rated current is 20.7 amps, the rated performance is estimated to be 11.3 kW and the rated torque is 41.5 Nm. In surface cooling, the rated current stands at 27.6 amps while the rated torque is estimated to be 59.2 Nm, the rated performance stands at 15.2 kW and the rated voltage is 344V.

To the mechanical data, the mass of the MKD112D-027-GP0-AN is 56kgs and the maximum speed is 3000 min-1. The theoretical maximum torque is 187Nm and the rotor moment of inertia is 350X10-4. The ambient temperature is 0 to 400C.



  • MKD112D027GP0AN
  • MKD112D 027 GP0 AN
  • mkd112d-027-gp0-an

MKD112D-027-GP0-AN Technical Specifications

Windings Code: 027
Motor Feedback: Resolver feedback
Driven Shaft: Shaft with Key
Holding Brake: Not Equipped
Connection Type: Connector at top
Protection Class: IP65
Weight: 45 kg
Ambient Temperature: 0 to +40°C
Insulation Class: Class F
Winding Temperature: 155°C
Shaft Sealing: Oil Sealing
Motor Type: Synchronous Servo Motor
Phase: 3-phase
Cooling Type: Standard
Maximum Speed: 6000 RPM
Power Rating: 16 kW
Torque Rating: 75 Nm
Voltage Rating: 400V
Encoder Type: Incremental encoder 2500 lines
