MKD112B-048-KP1-BN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911273473
The MKD112B-048-KP1-BN Servo Motor Series is manufactured by Rexroth Indramat Bosch. This motor has a Windings Code of 48 and a Multiturn Motor Encoder. This motor also is With a Key Driven Shaft and is Equipped with a Holding Brake.

MKD112B-048-KP1-BN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911273473
The MKD112B-048-KP1-BN Servo Motor Series is manufactured by Rexroth Indramat Bosch. This motor has a Windings Code of 48 and a Multiturn Motor Encoder. This motor also is With a Key Driven Shaft and is Equipped with a Holding Brake.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MKD112B-048-KP1-BN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

MKD112B-048-KP1-BN is a synchronous motor designed by Bosch Rexroth. It is one of the most reputable manufacturers in the industry. It has its headquarters in Germany. When it comes to motor size and length, these belong to the 112B category, which puts this motor into the category of large motors. The winding code that marks the motor output data in connection with the motor frame size and length is 048.

One of the crucial characteristics of this MKD112B variation is that it has a resolver encoder type. It features RSF with a built-in multiturn absolute encoder. The drive also has an absolute position detection type within 4096 mechanical rotations. Controlling the unit shouldn’t be a problem thanks to this feature. The motor has a shaft with a keyway that connects the machine elements to the motor shafts. Although it is an optional feature, it is interesting to note that the unit comes with a holding brake of 22Nm. When the motor is not in an energized state, you can use the holding brake to clamp the servo axis because the brake works on the “electrical release” principle.

The unit features a connection with a connector to side B, but as long as you follow the instructions and ensure that the motor is installed by skilled personnel, there should be no issues. As for the performance, the continuous torque at a standstill 100K is 15.9Nm and theoretical maximum torque goes up to 54Nm. The characteristic speed is 2000RPM, but the maximum can go up to twice as much. The unit is in the IP65 protection category, which indicates a high level of protection.



MKD112B-048-KP1-BN Documents

  • MKD 112B-048-KP1-BN
  • MKD-112B-048-KP1-BN
  • MKD112B-O48-KP1-BN
  • MKD112B048KP1BN
  • MKD112B 048 KP1 BN
  • mkd112b-048-kp1-bn

MKD112B-048-KP1-BN Technical Specifications

Driven Shaft: With a Key
Equipped: Holding Brake
Motor Encoder: Multiturn
Synchronous Servo Motor: MKD
Windings Code: 48
Motor Frame Size: 112
Motor Length: 28.0 Nm
Windings Code: 48
Motor Feedback: Resolver Feedback with integrated multiturn absolute encoder
Driven Shaft: shaft with key per DIN 6885-1 (with shaft sealing ring)
Holding Brake: with holding brake 22 Nm
Output Direction of Power Connection: Output connector in directon of side B
Other Design: none
