MKD041B-144-KP0-KN

  • Rated 4.4 (16 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911262600
  • Stock: In-Stock, Ships Today
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MKD041B-144-KP0-KN servo motor is a part of the MKD Servo Motor Series manufactured by Bosch Rexroth. This motor's winding code is 144, it incorporates Resolver feedback with integrated multiturn absolute encoder, operates with a Shaft with Key and is Not Equipped with a holding brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

MKD041B-144-KP0-KN

  • Rated 4.4 (16 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911262600
  • Stock: In-Stock, Ships Today
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MKD041B-144-KP0-KN servo motor is a part of the MKD Servo Motor Series manufactured by Bosch Rexroth. This motor's winding code is 144, it incorporates Resolver feedback with integrated multiturn absolute encoder, operates with a Shaft with Key and is Not Equipped with a holding brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a MKD041B-144-KP0-KN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The MKD041B-144-KP0-KN is a Digital AC Synchronous Servo Motor by Bosch Rexroth Indramat. The motor was developed as a part of the MKD motor series which is a line of motors running in permanent-magnet with electronic commutation. MKD motors were built to be reliable and efficient to use. This series of motors can run under hard conditions due to its fully shut motor layout degree protection feature.

The MKD041B-144-KP0-KN has a characteristic motor speed of 6000 RPM and has a continuous standstill torque of 2.7 Nm at Natural 60K and 2.9 Nm at 100K. Other than that, MKD041B-144-KP0-KN performs to 7.5 A and 8.2 A, at 60K and 100K Natural respectively, for its continuous standstill current. Its peak current is 34.0 A. At 20 degrees Celsius, its electric parameters are as follows: torque constant at 0.4 Nm, voltage constant at 36.3 V, and finally winding resistance at 1.8 ohms. To cap it all off, the MKD041B-144-KP0-KN has 3 pole pairs and a winding inductance of 5 mH.

At Natural 60K, MKD041B-144-KP0-KN runs at a rated speed of 3000 RPM and increases to 4500 RPM at 100K. For the rest of its rated data in Natural 60K, its torque, current, power, voltage, and frequency are 1.4 Nm, 2.8 A, 0.53 kW, 115 V, and 150 Hz respectively. In line with that at 100K Natural, all of these rates, from torque to frequency, increase to 1.5 Nm, 3 A, 0.88 kW, 170 V, and lastly, 225 Hz. The motor has no holding brake and connection box and has a winding code of 144 and a motor length of 2.7Nm. Lastly, the MKD041B-144-KP0-KN is a plain shaft driven motor that features a shaft sealing ring made with high quality materials to run under extreme conditions without being damaged by harmful oils and chemicals.



MKD041B-144-KP0-KN Documents

  • MKD041B144KP0KN
  • MKD041B 144 KP0 KN
  • mkd041b-144-kp0-kn
  • MKD41B-144-KP0-KN

MKD041B-144-KP0-KN Technical Specifications

Driven Shaft: Shaft with Key
Ambient Operating Temperature (°C): 0 to 40
Size Code: 041
Product Group: MKD
Length: B
Winding Code: 144
Holding Brake: No
Peak Current (A): 34
Feedback: Resolver Feedback with Integrated Multiturn Absolute Encoder
Housing Design: Standard

Frequently Asked Questions about MKD041B-144-KP0-KN


Q: What is the speed of the MKD041B-144-KP0-KN?

A: The MKD041B-144-KP0-KN has a characteristic speed of 6000 min-1. Its rated speed is 3000 min-1 at 60 K and 4500 min-1 at 100 K.

Q: What details does the MKD041B-144-KP0-KN type label include?

A: The type label of the MKD041B-144-KP0-KN includes its type designation, key technical details and certification. It helps to identify the motor and procure spare parts when there is a failure.

Q: In what orientation must the MKD041B-144-KP0-KN be stored and transported?

A: The MKD041B-144-KP0-KN must be stored and transported only in horizontal orientation. Its plastic protective sleeve on the shaft must remain intact during transport and storage.

Q: How many screws are needed to fix the flange to the MKD041B-144-KP0-KN?

A: Four M6 crews are needed to fix the flange to the motor. These screws must have a tightening torque of 10.4 Nm.

Q: What is the lifepsan of the bearings of the MKD041B-144-KP0-KN?

A: The bearings of the MKD041B-144-KP0-KN have a lifespan of 30,000 operating hours. They must be replaced when this service life has been reached.

Internal Product Review

  • ‘‘The MKD041B-144-KP0-KN can be installed in any position. It can be attached easily to any machine because of its flange design.’’
