MKD112C-058-GP0-AN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911288068
The Bosch Rexroth Indramat MKD112C-058-GP0-AN is a servo motor from the MKD Synchronous Motors series with a continuous torque at standstill of 38.0 Nm. It features a 192 mm flange size, a shaft with keyway and shaft seal, and uses resolver feedback for position detection. This motor does not include a holding brake and comes with a side A output connector.
Internal Product Review
The MKD112C-058-GP0-AN is a high-performance servo motor from the Bosch Rexroth Indramat MKD Synchronous Motors series, equipped with 38.0 Nm continuous torque at standstill and a shaft with keyway for secure mechanical coupling. Resolver feedback (RSF) allows for precise relative position detection, making it ideal for demanding automation tasks. This model stands out for its reliable output connector and integrated shaft seal, ensuring solid performance in industrial environments.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112C-058-GP0-AN is a three-phase servo motor produced by Bosch Rexroth Indramat for the MKD Synchronous Motors series. It drives rotary axes on packaging machines, transfer gantries, and metal-cutting spindles where precise acceleration and holding torque are required. Interfacing directly with the manufacturer’s digital drive modules, the motor converts electrical power into proportional mechanical motion so automated equipment can follow position or velocity commands generated by the control system. Its electromagnetic design supports repeatable positioning.
The listed dimensions show how the motor fits into a machine frame. The flange face measures 192 mm, and a 130 mm centering diameter keeps the stator concentric with bearings and couplings, minimizing runout. At standstill, the electromagnetic windings can generate 38.0 Nm of continuous torque, so lead-screw drives or indexing tables remain supported without excess heating. All electrical terminations sit on side A, and a combined output connector carries phase conductors alongside a low-level feedback channel, reducing enclosure penetrations. This layout keeps cable routing concentrated on one side of the housing.
Motion data leaves the housing through a resolver feedback transducer that supplies analog sine and cosine signals, and the drive interprets these values to reconstruct shaft angle during operation. The unit ships without a holding brake, so when power is removed, any load must be secured by external clamps or the drive’s torque control. A steel shaft with keyway provides positive mechanical locking with pulleys, and a shaft seal protects the internal bearings from coolant splash or airborne dust. In combination with the 112 frame size, the C length code and winding designation 058 set the thermal mass and resistance values that affect its acceleration profile.
