MKD112C-024-KG3-BN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911280056
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112C-024-KG3-BN is a servo motor from the MKD Synchronous Motors series. It features a continuous torque at standstill of 38.0 Nm and a holding brake torque of 70 Nm. The motor has resolver feedback with an integrated encoder for absolute position detection and includes a plain shaft with a shaft seal.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112C-024-KG3-BN is a servo motor manufactured by Bosch Rexroth Indramat and supplied within the MKD Synchronous Motors series. It converts current from a compatible inverter into controlled rotary motion for positioning axes, transfer systems, and machine tool applications that require repeatable speed and position control. Integrated feedback and a rigid motor structure help the axis respond smoothly during acceleration, holding, and reversing. This arrangement supports closed-loop operation where stable torque delivery and repeatable motion are required throughout repeated production cycles.
The mechanical interface uses a 130 mm pilot diameter for accurate centering on the machine, and the square mounting flange measures 192 mm on each side. A plain shaft transfers torque without a keyway, and the shaft seal helps keep lubricant away from internal motor components. At standstill, the motor can deliver 38.0 Nm continuously, while the built-in holding brake provides up to 70 Nm of holding torque when the axis must remain stationary after power is removed. Winding code 024 indicates the electrical winding configuration used by the matched drive, and the motor uses an output connector for power and feedback connections.
The motor uses resolver feedback with multi-turn absolute position tracking over more than 4096 revolutions, allowing the drive to retain position information without a homing cycle after each restart. Cables exit on side B, which can simplify routing when the rear of the motor faces a cable channel or enclosure wall. Frame size 112 indicates the housing class used for this motor, and the C construction length provides a balance between inertia and torque capacity for dynamic axis movement. This combination supports smooth motion in applications that need accurate response during starts, stops, and speed changes.
Frequently Asked Questions about MKD112C-024-KG3-BN:
Q: What type of feedback and encoder does the MKD112C-024-KG3-BN use?
A: The MKD112C-024-KG3-BN motor features resolver feedback with an integrated encoder for position detection.
Q: What is the continuous torque at standstill for the MKD112C-024-KG3-BN?
A: This model provides a continuous torque at standstill of 38.0 Nm.
Q: What is the holding brake torque of the MKD112C-024-KG3-BN motor?
A: The MKD112C-024-KG3-BN is equipped with a holding brake capable of delivering 70 Nm of torque.
Q: Where is the electrical connection located on the MKD112C-024-KG3-BN?
A: Connection for this motor is made via an output connector located on Side B.
Q: What is the shaft design of the MKD112C-024-KG3-BN motor?
A: This motor features a plain shaft with a shaft seal for reduced leakage and added protection.
